Sony D-EJ775 - Page 37

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
37
D-EJ775
R419 1-216-864-11 METAL CHIP 0 5% 1/10W
R422 1-216-864-11 METAL CHIP 0 5% 1/10W
R424 1-216-041-00 METAL CHIP 470 5% 1/10W
R425 1-216-841-11 METAL CHIP 47K 5% 1/10W
R426 1-217-671-11 RES-CHIP 1 5% 1/10W
R428 1-216-864-11 METAL CHIP 0 5% 1/10W
R429 1-216-845-11 METAL CHIP 100K 5% 1/10W
R430 1-216-857-11 METAL CHIP 1M 5% 1/10W
R431 1-216-853-11 METAL CHIP 470K 5% 1/10W
R435 1-216-845-11 METAL CHIP 100K 5% 1/10W
R436 1-216-857-11 METAL CHIP 1M 5% 1/10W
R437 1-216-853-11 METAL CHIP 470K 5% 1/10W
R438 1-216-853-11 METAL CHIP 470K 5% 1/10W
R601 1-216-817-11 METAL CHIP 470 5% 1/10W
R602 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R603 1-216-845-11 METAL CHIP 100K 5% 1/10W
R604 1-233-810-21 RES, NETWORK 100K (3216)
R610 1-216-864-11 METAL CHIP 0 5% 1/10W
R611 1-216-864-11 METAL CHIP 0 5% 1/10W
R616 1-216-817-11 METAL CHIP 470 5% 1/10W
R620 1-216-805-11 METAL CHIP 47 5% 1/10W
R626 1-216-833-11 METAL CHIP 10K 5% 1/10W
R627 1-216-817-11 METAL CHIP 470 5% 1/10W
R628 1-216-864-11 METAL CHIP 0 5% 1/10W
R629 1-216-817-11 METAL CHIP 470 5% 1/10W
R630 1-216-864-11 METAL CHIP 0 5% 1/10W
R631 1-216-817-11 METAL CHIP 470 5% 1/10W
R633 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R636 1-216-857-11 METAL CHIP 1M 5% 1/10W
R801 1-216-845-11 METAL CHIP 100K 5% 1/10W
R802 1-216-833-11 METAL CHIP 10K 5% 1/10W
R803 1-216-833-11 METAL CHIP 10K 5% 1/10W
R804 1-216-833-11 METAL CHIP 10K 5% 1/10W
(FR)
R807 1-216-857-11 METAL CHIP 1M 5% 1/10W
R809 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R810 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R811 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R812 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R813 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R814 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R815 1-216-833-11 METAL CHIP 10K 5% 1/10W
R816 1-216-849-11 METAL CHIP 220K 5% 1/10W
R817 1-216-845-11 METAL CHIP 100K 5% 1/10W
R818 1-216-809-11 METAL CHIP 100 5% 1/10W
R819 1-216-821-11 METAL CHIP 1K 5% 1/10W
R820 1-216-833-11 METAL CHIP 10K 5% 1/10W
R824 1-216-817-11 METAL CHIP 470 5% 1/10W
R830 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
< SWITCH >
S801 1-762-805-41 SWITCH, PUSH (1 KEY) (OPEN)
S802 1-762-078-11 SWITCH, SLIDE (HOLD)
S803 1-762-078-11 SWITCH, SLIDE (G-PROTECTION)
S805 1-771-248-11 SWITCH, TACTILE (N>)
S806 1-771-248-11 SWITCH, TACTILE (.)
S807 1-771-248-11 SWITCH, TACTILE (x, CHARGE)
S808 1-771-248-11 SWITCH, TACTILE (SOUND)
S809 1-771-248-11 SWITCH, TACTILE (VOL +)
S810 1-771-248-11 SWITCH, TACTILE (VOL -)
S811 1-771-248-11 SWITCH, TACTILE (MENU)
< VARISTOR >
VDR101 1-804-499-21 VARISTOR, CHIP
VDR201 1-804-499-21 VARISTOR, CHIP
VDR301 1-804-499-21 VARISTOR, CHIP
VDR801 1-801-862-11 VARISTOR, CHIP
VDR815 1-804-499-21 VARISTOR, CHIP
< VIBRATOR >
X601 1-795-218-21 VIBRATOR, CERAMIC (16.934MHz)
**************************************************************
* A-3021-759-A MAIN BOARD, COMPLETE (SUFFIX-12) (JE)
* A-3021-760-A MAIN BOARD, COMPLETE (SUFFIX-12) (FR)
* A-3021-812-A MAIN BOARD, COMPLETE (SUFFIX-12)
(EXCEPT FR, JE)
**********************
< BATTERY TERMINAL >
BT400 3-239-264-01 TERMINAL (+), BATTERY
BT401 3-239-263-01 TERMINAL BOARD (RELAY), BATTERY
BT402 3-239-265-01 TERMINAL (-), BATTERY
< CAPACITOR >
C102 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C106 1-125-899-11 TANTALUM CHIP 220uF 20% 4V
C107 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C206 1-125-899-11 TANTALUM CHIP 220uF 20% 4V
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-110-569-11 TANTALUM CHIP 47uF 20% 6.3V
C303 1-115-156-11 CERAMIC CHIP 1uF 10V
C304 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C305 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C307 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C401 1-117-887-11 TANTALUM CHIP 220uF 20% 6.3V
C402 1-107-686-11 TANTALUM CHIP 4.7uF 20% 16V
C404 1-111-253-11 TANTALUM CHIP 100uF 20% 6.3V
C405 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C406 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C407 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C408 1-128-964-11 TANTALUM CHIP 100uF 20% 6.3V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C410 1-115-156-11 CERAMIC CHIP 1uF 10V
C412 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C413 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C415 1-117-887-11 TANTALUM CHIP 220uF 20% 6.3V
C416 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C417 1-115-156-11 CERAMIC CHIP 1uF 10V
C418 1-115-156-11 CERAMIC CHIP 1uF 10V
C422 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C425 1-104-908-11 TANTALUM CHIP 47uF 20% 4V
C426 1-164-156-11 CERAMIC CHIP 0.1uF 25V
MAIN (SUFFIX-11) MAIN (SUFFIX-12)
