SERVICE MANUAL
LEVEL 2
DCR-DVD306E/DVD308/DVD308E/DVD708/DVD708E_L2
Ver. 1.3 2007.07
Sony EMCS Co.
9-852-174-84
2007G0500-1
© 2007.7
Published by Kohda TEC
SUPPLEMENT-1
File this supplement with the service manual.
(DI07-044)
• Change of Repair Parts
US Model
Canadian Model
AEP Model
UK Model
East European Model
North European Model
E Model
Australian Model
Hong Kong Model
Chinese Model
Korea Model
Argentine Model
Brazilian Model
Japanese Model
RMT-835
DCR-DVD306E/DVD308/DVD308E/
DVD708/DVD708E
0 101 A-1212-602-A SERVICE (DDX-C2000) BLOCK ASSY
SP901 1-825-262-51 SPEAKER (1.6CM)
Ref. No. Part No. Description Ref. No. Part No. Description
0 101 A-1212-602-A SERVICE (DDX-C20000) BLOCK ASSY
SP901 1-825-260-41 LOUD SPEAKER (1.6CM)
5-1. EXPLODED VIEWS
5. REPAIR PARTS LIST
Page Former New
5-4
5-6
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
0印の部品，または0印付きの点線で囲まれた部品は，
安全性を維持するために重要な部品です。
従って交換時は，必ず指定の部品を使用して下さい。
To Next Page
