Sony DCR-SR190E - Mounted Parts Location

4-48E
DCR-SR190E/SR200/SR200C/SR200E/SR290E/SR300/SR300C/SR300E_L2
PD-324 BOARD
no mark : side A
*
mark : side B
4-3. PRINTED WIRING BOARDS
PD-324
4-4. MOUNTED PARTS LOCATION
C6101 C-4
C6102 C-4
C6103 B-4
C6105 A-4
C6107 A-3
C6108 A-4
C6109 A-4
C6111 B-4
C6112 B-4
C6113 B-4
C6114 B-4
C6115 B-4
C6116 B-3
C6117 B-3
C6119 B-4
C6120 B-4
C6121 B-4
C6123 C-3
C6124 B-3
C6125 C-3
C6126 C-3
CN6101 A-2
CN6102 C-4
CN6104 C-4
CN6105 C-2
D6105 C-3
* D6106 A-6
* D6107 B-6
* D6108 C-6
FB6101 B-3
IC6102 B-4
L6101 A-4
L6102 B-4
L6103 B-3
Q6101 C-4
Q6102 C-4
Q6107 A-5
Q6108 B-3
Q6109 B-3
Q6110 A-6
Q6111 C-3
Q6112 A-5
Q6113 A-5
R6101 C-4
R6102 C-5
R6104 C-5
R6105 C-5
R6109 A-4
R6110 A-4
R6112 A-4
R6115 B-4
R6122 B-4
R6130 A-5
R6132 A-6
R6133 B-3
R6134 A-6
R6135 B-3
R6136 A-6
R6137 C-3
R6138 B-6
R6139 A-6
R6140 A-5
R6141 A-5
R6142 A-5
R6143 A-5
R6144 A-5
R6145 C-3
R6152 B-5
R6153 B-5
R6154 B-5
R6155 A-5
