Sony DCR-SR190E - Cabinet (R) Block Disassembly

2-7
DCR-SR190E/SR200/SR200C/SR200E/SR290E/SR300/SR300C/SR300E_L2
EXPLODED VIEW
HARDWARE LIST
Follow the disassembly in the numerical order given.
1 CK-175 Block (1-1 to 1-5)
2 LCD Block (2-1 to 2-4)
2-1-6. CABINET (R) BLOCK
CK-175
FP-620
1CK-175 Board
2LCD Block
1-3
1-1 (#12)
1-4
1-5
1-2
2-1 (#12)
2-4
2-2 (#12)
2-3
