Ref. No. Part No. Description Ref. No. Part No. Description
DCR-SR190E/SR200/SR200C/SR200E/SR290E/SR300/SR300C/SR300E_L2
C6114 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C6115 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
* C6116 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
* C6117 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C6119 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6120 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6121 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6123 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6124 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C6125 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6126 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
* CN6101 1-785-905-51 FFC/CONNECTOR, FPC (ZIF) 24P
* CN6102 1-794-322-51 FFC/CONNECTOR, FPC (ZIF) 6P
CN6103 1-816-180-71 CONNECTOR, FPC (ZIF) 6P
* CN6105 1-785-905-51 FFC/CONNECTOR, FPC (ZIF) 24P
< DIODE >
D6105 6-500-941-01 DIODE MAZS056008S0
* D6106 6-501-597-01 DIODE NSSW008DT-T108
* D6107 6-501-597-01 DIODE NSSW008DT-T108
* D6108 6-501-597-01 DIODE NSSW008DT-T108
< FERRITE BEAD >
FB6101 1-400-331-11 FERRITE, EMI (SMD) (1005)
< IC >
IC6102 8-753-229-98 IC CXM3006CR-T4
< COIL >
L6101 1-400-588-11 INDUCTOR 10uH
L6102 1-400-588-11 INDUCTOR 10uH
L6103 1-400-588-11 INDUCTOR 10uH
< TRANSISTOR >
Q6101 8-729-427-37 TRANSISTOR XP411F-TXE
Q6102 8-729-427-67 TRANSISTOR XP421F-TXE
Q6107 6-550-239-01 TRANSISTOR DTA144EMT2L
Q6108 6-550-234-01 TRANSISTOR UNR32A300LS0
Q6109 6-551-184-01 TRANSISTOR MCH6305-TL-E-S
Q6110 8-729-054-48 TRANSISTOR UP04601008S0
Q6111 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q6112 8-729-054-49 TRANSISTOR UP04401008S0
Q6113 8-729-054-48 TRANSISTOR UP04601008S0
< RESISTOR >
R6101 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R6102 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R6104 1-218-990-11 SHORT CHIP 0
R6105 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R6109 1-218-975-11 RES-CHIP 68K 5% 1/16W
R6110 1-218-949-11 RES-CHIP 470 5% 1/16W
R6112 1-208-934-11 METAL CHIP 91K 0.5% 1/16W
R6115 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R6122 1-218-965-11 RES-CHIP 10K 5% 1/16W
R6130 1-208-898-81 METAL CHIP 3K 0.5% 1/16W
R6132 1-218-969-11 RES-CHIP 22K 5% 1/16W
R6133 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6134 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R6135 1-218-981-81 RES-CHIP 220K 5% 1/16W
R6136 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R6137 1-218-978-11 RES-CHIP 120K 5% 1/16W
R6138 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6139 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R6140 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R6141 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R6142 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R6143 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6144 1-211-969-11 METAL CHIP 10 0.5% 1/10W
R6145 1-218-989-11 RES-CHIP 1M 5% 1/16W
R6152 1-218-990-11 SHORT CHIP 0
R6153 1-218-990-11 SHORT CHIP 0
R6154 1-218-990-11 SHORT CHIP 0
R6155 1-216-864-11 SHORT CHIP 0
A-1244-921-A ST-159 BOARD, COMPLETE
**********************
< CAPACITOR >
C5201 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5202 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C5203 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C5204 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
0 C5206 1-112-766-11 ELECT 70uF 99% 330V
< CONNECTOR >
* CN5201 1-816-647-51 FFC/FPC CONNECTOR (LIF) 18P
* CN5202 1-819-257-51 CONNECTOR, FFC/FPC (ZIF) 14P
< DIODE >
D5201 6-501-096-01 DIODE CRF02 (TE85R)
0 D5202 6-501-096-01 DIODE CRF02 (TE85R)
D5204 8-719-083-91 DIODE EDZ TE61 6.8B
< IC >
0 IC5201 6-707-554-01 IC TPS65552DGQR
< COIL >
L5201 1-412-027-11 INDUCTOR 2.2uH
< TRANSISTOR >
0* Q5201 6-551-447-01 TRANSISTOR TIG022TS-S-TL-E
< RESISTOR >
R5201 1-208-947-11 METAL CHIP 330K 0.5% 1/16W
R5202 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R5203 1-216-864-11 SHORT CHIP 0
R5204 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R5205 1-216-809-11 METAL CHIP 100 5% 1/10W
R5206 1-218-989-11 RES-CHIP 1M 5% 1/16W
PD-324 ST-159
• Refer to page 5-1 for mark 0.
