Sony DCR-SR210E - Page 38

2-10E
DCR-SR210E/SR220/SR220D/SR220E/
HDR-SR10/SR10D/SR10E_L2
2-2-8. PANEL BLOCK
Follow the disassembly in the numerical order given.
1 Hinge Assy (1-1 to 1-12)
2 LCD (2-1 to 2-5)
3 PD-356 Board (3-1 to 3-2)
EXPLODED VIEW
HARDWARE LIST
A
A
B
C
D
E
B
D
E
C
PD-356
1 Hinge Assy
1-1
(#2)
1-2
(Claw)
1-3
(Claw)
1-4
2-1
2-2
1-6
(#2)
1-7
(Claw)
1-9
1-10
(Peel off the
Flexible Board)
1-11
1-12
1-8
1-5
3 PD-356 Board
3-1
3-2
2 LCD
HELP11
HELP11
2-4
(#11)
2-5
2-3
