DCR-SR210E/SR220/SR220D/SR220E/
HDR-SR10/SR10D/SR10E_L2
HELP05
VC-516 Board
Shield Sheet (AN)
Be careful not to overlap it into
the pattern prohibition area.
Be careful not to bring it out of IC.
LD-230 Board
Flexible Board
(Lens Barrier Unit)
Insert the Flexible Board
in to the Claws.
HELP06
