HELP
DCR-SR210E/SR220/SR220D/SR220E/
HDR-SR10/SR10D/SR10E_L2
Claws
Push the
Flexible Board
LD-230 Board
Flexible Board
(Flash Unit)
HELP07
Lens Flame (L(700))
Pass the Flexible Board (Lens Unit) through
between the Lens Unit and the Lens Frame (L(700)).
Flexible Board
(Lens Unit)
Lens Unit
HELP08
