Sony DCR-SR210E - Page 43

HELP
DCR-SR210E/SR220/SR220D/SR220E/
HDR-SR10/SR10D/SR10E_L2
CM Radiation Sheet (700)
Lib
CMOS Block Assy
(CM-093 Board)
Lens Frame
(R(700))
Be sure not to load to CM-093 Board
and not to bend the sheet.
HELP09
CK-196 Board
Lib
Harnesses
(Loud Speaker(1.6cm))
Lib
Dowel
Harness
(Red)
Harness
(Black)
NS Nkob
Engage the NS knob with
the Slide witch.
Slide Switch
HELP10
