5-14
DCR-TRV255E/TRV260/TRV265/TRV265E
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
CD-471 FP-300 FP-301 FP-302 FP-792 FP-802 PD-204 (TYPE C)
Note: Be sure to read “Precautions for Replacement of
CCD Imager” on page 4-8 when changing the
CCD imager.
A-7111-947-A CD-471 BOARD, COMPLETE
***********************
(IC951 is not included in this complete board.)
< CAPACITOR >
C951 1-126-395-11 ELECT CHIP 22uF 20% 16V
C953 1-128-994-21 ELECT CHIP 47uF 20% 10V
C955 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN951 1-815-762-11 CONNECTOR, FFC/FPC 14P
< IC >
IC951 A-7013-401-A CCD BLOCK ASSY (CCD IMAGER) (Note)
(TRV255E/TRV265E)
IC951 A-7016-724-A CCD BLOCK ASSY (CCD IMAGER) (Note)
(TRV260/TRV265)
< COIL >
L951 1-469-528-91 INDUCTOR 100uH
< TRANSISTOR >
Q951 8-729-117-73 TRANSISTOR 2SC4178-F14
< RESISTOR >
R952 1-218-940-11 RES-CHIP 82 5% 1/16W
R953 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R970 1-216-864-11 SHORT CHIP 0
FP-300 FLEXIBLE BOARD (Not Supplied)
********************
< PHOTO TRANSISTOR >
Q001 8-729-907-25 PHOTO TRANSISTOR PT4850F (TAPE TOP)
FP-301 FLEXIBLE BOARD (Not Supplied)
********************
< DIODE >
D001 8-719-988-42 DIODE GL453S (TAPE LED)
FP-302 FLEXIBLE BOARD (Not Supplied)
********************
< PHOTO TRANSISTOR >
Q002 8-729-907-25 PHOTO TRANSISTOR PT4850F (TAPE END)
1-860-929-11 FP-792 FLEXIBLE BOARD
********************
(D001, D002 and D003 are not included in this flexible board.)
< DIODE >
D001 6-500-744-01 DIODE NSPW500BS-TL2 (VIDEO LIGHT)
D002 6-500-744-01 DIODE NSPW500BS-TL2 (VIDEO LIGHT)
D003 6-500-744-01 DIODE NSPW500BS-TL2 (VIDEO LIGHT)
FP-802 FLEXIBLE BOARD (Not Supplied)
********************
< HOLE ELEMENT >
H001 8-719-033-37 ELEMENT, HALL HW-105C (T REEL)
H002 8-719-033-37 ELEMENT, HALL HW-105C (S REEL)
< SWITCH >
S001 1-692-614-11 SWITCH, PUSH (3 KEY) (REC PROOF)
S002 1-572-688-11 SWITCH, PUSH LEVER (1 KEY) (C.C. LOCK)
A-7111-949-A PD-204 BOARD, COMPLETE (TYPE C)
***********************
< CAPACITOR >
C6001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6002 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C6003 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6004 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6005 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6006 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6007 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C6009 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6010 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C6011 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C6012 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6013 1-100-371-11 CERAMIC CHIP 12PF 5% 3.15KV
C6015 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C6019 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C6020 1-110-457-11 ELECT CHIP 3.3uF 20% 25V
C6022 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6024 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C6026 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C6027 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6028 1-115-407-11 ELECT CHIP 10uF 16V
< CONNECTOR >
CN6001 1-794-997-11 PIN, CONNECTOR 20P
CN6003 1-764-709-11 FFC/CONNECTOR, FPC (LIF) 10P
CN6004 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN6005 1-816-176-11 CONNECTOR, FFC/FPC (ZIF) 6P
< DIODE >
D6004 8-719-073-01 DIODE MA111-(K8).S0
D6009 8-719-071-34 DIODE RB521S-30-TE61
< FERRITE BEAD >
FB6001 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC6001 6-705-329-01 IC CM7104L42-T4
To Next Page
