Sony DMX-P01 User Manual (English)

Other manuals for Sony DMX-P01

Quick Start Guide2 pages

Quick Setup4 pages

Questions and Answers:

C
Christine HartAug 7, 2025
How to fix a Sony Music Mixer when the power does not turn on?
- K
  Kenneth MartinAug 7, 2025
  If the power doesn't turn on in your Sony Music Mixer, there could be several reasons. First, check that the batteries are inserted with the correct + and – polarities as shown on page 39. Second, the batteries may be low, in which case you should replace all eight internal batteries with new ones, as described on page 38. Lastly, ensure that the screws on the battery compartment cover are tightened correctly, as shown on page 39.
O
olivia07Aug 11, 2025
Why do the batteries run low quickly on my Sony DMX-P01?
- T
  Terri EdwardsAug 11, 2025
  If the batteries in your Sony Music Mixer are running low quickly, it could be due to a couple of reasons. You may need to replace the eight internal batteries with new ones, as mentioned on page 38. Also, if you're using manganese batteries, switch to alkaline batteries as instructed on page 38.
T
Thomas KleinAug 15, 2025
Why doesn't the MASTER volume activate on my Sony Music Mixer?
- E
  elizabeth07Aug 15, 2025
  If the MASTER volume does not activate to adjust the level of the signal output from the COAXIAL connector on your Sony Music Mixer, it might be because the S/PDIF/CASCADE switch is set to CASCADE. To resolve this, set the switch to S/PDIF. The CASCADE function is only needed when two DMX-P01s are connected in cascade; otherwise, the MASTER volume control won't work, as explained on page 16.
V
Valerie BeardAug 20, 2025
What to do if the sampling rate cannot be switched on Sony DMX-P01?
- N
  Nicholas HowardAug 20, 2025
  If the sampling rate cannot be switched on your Sony Music Mixer, it is possible that the unit was not restarted after the SAMPLING RATE switch setting was changed. Restart the unit after changing the sampling rate as described on page 16. The setting of the SAMPLING RATE switch is applied only when the unit is restarted.
P
Peggy FloresAug 23, 2025
How to stop Sony Music Mixer resetting to default settings?
- G
  gutierrezbrittanyAug 25, 2025
  If each time the power is turned on, the parameters on your Sony Music Mixer are reset to the default settings, it is likely that the POWER ON MODE is set to DEFAULT on the POWER ON MODE sub-menu. You can change this setting on the POWER ON MODE sub-menu to LAST or SCENE 0, as described on page 33.
M
mgreenAug 28, 2025
Why don't the level meter and meter scale match on my Sony Music Mixer?
- A
  annamichaelAug 28, 2025
  If the indication of the level meter and the meter scale do not match on your Sony Music Mixer, it means that the meter scale sheet attached and the meter display selected using the METER SELECT sub-menu are different. Replace the meter scale sheet with one that matches the meter you are using, as described on pages 32 and 41.
L
Lisa Rodriguez DVMSep 1, 2025
Why is there no power to the DC OUT connector on Sony DMX-P01 Music Mixer?
- A
  Amy MathewsSep 1, 2025
  The external battery output function of your Sony Music Mixer activates only when the unit works on the external battery. If power is not being supplied to the DC OUT connector, ensure you are using the external battery instead of the internal batteries, as mentioned on page 38.

Sony DMX-P01 Specifications

General

Channels	4
Type	Digital Mixer
Frequency Response	20 Hz - 20 kHz
Sampling Rate	48 kHz
A/D Conversion	24-bit
D/A Conversion	24-bit
EQ	3-band
Phantom Power	Yes
Power Source	AC Adapter
Signal-to-Noise Ratio	90 dB or more
Inputs	2 XLR/TRS combo, 2 RCA
