4-14
DNW-A100/A50/A45
DNW-A100P/A50P/A45P
4-2-2. Operation Check
Equipment
BNC cable
Pre-recorded tape or Alignment tape
*
*
: SR5-1 (For 525/60 system)
SR5-1P (For 625/50 system)
Check
n
Check that the EXT button on the lower control panel illuminates.
(1) Connect the BNC cable between the SDTI INPUT on the connector panel and the SDTI OUTPUT (1
or 2).
(2) Set the OUT REF switch on the sub control panel to REF.
(3) Insert the pre-recorded tape or alignment tape, and play back.
(4) Select the SDTI by the VIDEO INPUT SELECT switch on the upper control panel.
(5) Check that the SDTI indicator illuminates.
n
If the SDTI indicator does not illuminate or blinks, check that the harnesses or cables are connected
accurately.
(6) Eject the tape.
(7) Reset the OUT REF switch on the sub control panel to its previous state.
(8) Disconnect the BNC cable.
4-2. CP-300 Board (BKNW-103)
To Next Page
