21
DP-RF6000
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
•SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference
number, please include the board.
SECTION 4
ELECTRICAL PARTS LIST
TX
• Abbreviation
CND : Canadian model
KR : Korea model
A-1179-107-A CHARGE BOARD, COMPLETE (US, CND)
A-1182-488-A CHARGE BOARD, COMPLETE (AEP, KR)
************************
3-254-058-11 SCREW
************************************************************
A-1179-109-A FUNCTION BOARD, COMPLETE (US, CND)
A-1182-490-A FUNCTION BOARD, COMPLETE (AEP, KR)
*************************
< CAPACITOR >
C551 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C552 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C553 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C554 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C555 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN501 1-568-955-11 PIN, CONNECTOR 6P
< RESISTOR >
R551 1-216-821-11 METAL CHIP 1K 5% 1/10W
R552 1-216-821-11 METAL CHIP 1K 5% 1/10W
R553 1-216-821-11 METAL CHIP 1K 5% 1/10W
R554 1-216-821-11 METAL CHIP 1K 5% 1/10W
R555 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S501 1-692-591-21 SWITCH, SLIDE (EFFECT)
S502 1-771-350-21 SWITCH, SLIDE (INPUT SELECT)
S503 1-771-350-21 SWITCH, SLIDE (COMPRESSION)
************************************************************
A-1176-716-A TX BOARD, COMPLETE (US, CND)
A-1182-486-A TX BOARD, COMPLETE (AEP)
A-1188-957-A TX BOARD, COMPLETE (KR)
*******************
A-1176-713-A TX-RF BLOCK (US, CND)
A-1182-505-A TX-RF BLOCK (AEP)
A-1188-955-A TX-RF BLOCK (KR)
1-819-735-11 CONNECTOR, CHARGE
< CAPACITOR >
C001 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C002 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C003 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C008 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C009 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C010 1-124-589-11 ELECT 47uF 20% 16V
C014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C051 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C052 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C053 1-124-233-11 ELECT 10uF 20% 16V
C054 1-124-233-11 ELECT 10uF 20% 16V
C055 1-124-584-00 ELECT 100uF 20% 6.3V
C056 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C057 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C058 1-124-233-11 ELECT 10uF 20% 16V
C059 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C060 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C061 1-124-233-11 ELECT 10uF 20% 16V
C062 1-124-234-00 ELECT 22uF 20% 16V
C063 1-124-234-00 ELECT 22uF 20% 16V
C064 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C065 1-125-972-61 ELECT 100uF 20% 16V
C066 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C067 1-124-233-11 ELECT 10uF 20% 16V
C068 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C069 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C070 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C071 1-124-233-11 ELECT 10uF 20% 16V
C072 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C073 1-124-233-11 ELECT 10uF 20% 16V
C074 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C075 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C076 1-124-233-11 ELECT 10uF 20% 16V
C077 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C078 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C080 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C202 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C203 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C205 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C206 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C207 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
CHARGE FUNCTION
