Sony DP-RF6000 - IC Pin Function Descriptions

15
DP-RF6000
2-9. IC Pin Function Descriptions
• IC201 MB90488BPFV-G-150E1 SYSTEM CONTROL (TX BOPARD)
Pin No. Pin Name I/O Description
1 to 8 P22 to P27, P30, P31 — Not used (Open)
9 VSS — Ground
10 P32 — Not used (Open)
11 P33 I COMPRESSION switch signal input (L : ON,H:OFF)
12 P34 I INPUT SELECT switch signal input (L : DIGITAL,H:ANALOG)
13 P35 I EFFECT switch signal input (L : MUSIC)
14 P36 I EFFECT switch signal input (L : CINEMA)
15 P37 I EFFECT switch signal input (L : EFFECT OFF)
16 SIN2 I Serial data input from CS494003-CQZ
17 SOT2 O Serial data output to CS494003-CQZ
18 SCK2 O Serial clock output to CS494003-CQZ
19, 20 P43, P44 — Not used (Open)
21 VCC5 — Power supply (+3.3V)
22 to 24 P45 to P47 — Not used (Open)
25 SIN0 I Serial data input for flash (Open)
26 SOT0 O Serial data output for flash (Open)
27 SCK0 O Serial clock signal output for flash (Open)
28 P73 I DSP_NOSG signal input from CS494003-CQZ
29 P74 I DEC Interrupt request signal input from CS494003-CQZ
30 P75 I DSP Interrupt request signal input from CS494003-CQZ
31 P76 I DSP HINBSY signal input from CS494003-CQZ
32 P77 O DEC chip select signal output to CS494003-CQZ
33 AVCC — Power supply terminal (+3.3V)
34 AVRH I A/D converter external reference power supply input
35 AVSS — Ground
36 AN0 I Battery temperature detection signal input
37 AN1 I Battery voltage level detection signal input
38 P62 O DSP reset signal output to CS494003-CQZ
39 P63 O DSP Chip select signal output to CS494003-CQZ
40 VSS — Ground
41 to 44 P64 to P67 — Not used (Open)
45 P80 — Not used(Pull up)
46 P81 — Not Used(Pull down)
47 MD0 I Mode setting input terminal
48 MD1 I Mode setting input terminal
49 MD2 I Mode setting input terminal
50 to 55 P82 to P87 — Not used (Open)
56 SIN1 I Serial data input from LC89052T-TLM-E
57 SOT1 O Serial data output to LC89052T-TLM-E
58 SCK1 O Serial clock output to LC89052T-TLM-E
59 P93 — Not used (Pull down)
60 to 65 P94 to P97, PA0, PA1 — Not used (Open)
66 PA2 I Function setting signal input from LC89052T-TLM-E
67 PA3 I PCM detection signal input from LC89052T-TLM-E
68 to 71 P50 to P53 — Not used (Open)
72 p54 I Emphasis signal input from LC89052T-TLM-E
73 P55 O Chip select signal output to LC89052T-TLM-E
74 P56 I Error signal input from LC89052T-TLM-E
