DP-RF6000
Pin No. Pin Name I/O Description
75 XRST I System reset signal input
76 P57 O Reset signal output to LC89052T-TLM-E
77 X1A — Not used (Open)
78 X0A — Not used (Connect to Ground)
79 VSS — Ground
80 X0 O Clock output (4MHz)
81 X1 I Clock input (4MHz)
82 VCC3 — Power supply (+3.3V)
83 P00 O REG+9V Main Power supply ON/OFF signal output
84 P01 I Battery detection signal input
85 P02 O Battery charge ON/OFF signal output
86 to 89 P03 to P06 — Not used (Open)
90 P07 O 5V DC-DC converter ON/OFF signal output
91 P10 I Channel SYNC signal input from TX-RF block
92 P11 O RF output enable signal output to TX-RF block
93 P12 I ID state signal input from TX-RF block
94 P13 O IA8 Reset signal output to TX-RF block
95 P14 O RF LED drive signal output
96 P15 O AAC LED drive signal output
97 P16 O DTS LED drive signal output
98 P17 O DOLBY PRO LOGIC II LED drive signal output
99 P20 O DOLBY DIGITAL LED drive signal output
100 P21 O CHARGE LED drive signal output
