17
DP-RF6000
Pin No. Pin Name I/O Description
• IC1201 CS494003-CQZ DECODER/DSP (TX BOARD)
1 UHS0 I Mode select signal input
2 UHS1 I Mode select signal input
3 XINTREQ O DSP Interrupt request signal output to MB90488BPFV-G-150E1
4 FSCDIN I Serial data input from MB90488BPFV-G-150E1
5 GPIO20 — Not used (Open)
6 FSCCLK I Serial clock signal input from MB90488BPFV-G-150E1
7 FHS2, FSCDOUT O Serial data output to MB90488BPFV-G-150E1
8 GPIO21 — Not used (Open)
9 FDAT7 — Not used (Open)
10 VDD6 — Power supply (+2.5V)
11 VSS6 — Ground
12 FHS0 I Mode select signal (Pull up)
13 FHS1 I Mode select signal (Pull down)
14 FDAT6 — Not used (Open)
15 XFCS I DEC Chip select signal input from MB90488BPFV-G-150E1
16 XFINTREQ O DEC Interrupt request signal output to MB90488BPFV-G-150E1
17 FDBCK — Not used (Pull up)
18 FDAT5 — Not used (Open)
19 FDAT4 — Not used (Open)
20 VDD7 — Power supply (+2.5V)
21 VSS7 — Ground
22 FDAT3 — Not used (Open)
23 FDBDA I Not used (Pull up)
24 FDAT2 — Not used (Open)
25 DBDA I Not used (Pull up)
26 DBCK I Not used (Pull up)
27 FDAT1 — Not used (Open)
28 TEST I Test terminal (Connect to Ground)
29 FDAT0 — Not used (Open)
30 GPIO16 — Not used (Open)
31 GPIO15 O DSP_NOSG signal output to MB90488BPFV-G-150E1
32 GPIO14 — Not used (Open)
33 WE — Not used (Open)
34 to 38 D0 to D4 — Not used (Open)
39 DQM0 — Not used (Open)
40 D5 — Not used (Open)
41 VSSSD4 — Ground
42 VDDSD4 — Power supply (+3.3V)
43,44 D6, D7 — Not used (Open)
45 DQM1 — Not used (Open)
46,47 A18, A17 — Not used (Open)
48 NC5 — Not used (Connect to Ground)
49 A16 — Not used (Open)
50 VSSSD3 — Ground
51 VDDSD3 — Power supply (+3.3V)
52 to 56 A15 to A11 — Not used (Open)
57 VSSSD2 — Ground
58 VDDSD2 — Power supply (+3.3V)
