Sony DPP-EX50 - Jd-46

8-6
DPP-EX50 V2
8-6
2
3
4
5
ABCDEFGH
1
R821
180
NM
C821
0.01uF
PH821
DG-105F3
CN821
178594621
4312
54
GND(DIGITAL) 3
JUMMING_DET_LED 2
JUMMING_DET_SENS 1
JD-46, PE-46, RM-46JD-46, PE-46, RM-46
R831
150
NM
C831
0.01uF
PH831
DG-105F3
CN831
178594621
4312
54
GND(DIGTAL) 3
PAPER_EDGE_LED 2
PAPER_EDGE_SENS 1
$320589601
Q841
LTB-305R4
CN841
177061921
43
5V 2
RIBBON_MARK_SENS 1
JD-46
PE-46
RM-46
