6-5
DPP-EX7 V2
BVTT
2.6x5
BVTT
2.6x5
BVTT
2.6x5
BVTT
2.6x5
BVTT
2.6x5
BVTT
2.6x5
302
301
303
304
305
No. Part No. SP Description
301 X-3168-395-8 s CHASSIS ASSY
302 X-3168-397-2 s REEL ASSY, S
303 X-4622-925-2 s REEL ASSY, T
304 1-763-602-13 o MOTOR, DC (STEPPING MOTOR)
305 3-207-080-01 s ROLLER, E CAPSTAN
7-685-861-01 s SCREW +BVTT 2.6X5
Mecha Deck Block 2
