2-4
DSC-H7/H9_L2
HARDWARE LIST
HARDWARE LIST
EXPLODED VIEW
EXPLODED VIEW
2-1-3. SY-177 BOARD, SY FRAME, CCD BLOCK ASSY AND LENS BLOCK ASSY
1 SY-177 Board
1-1
1-2
1-3
1-4
1-5
1-6
1-7 (#12)
1-9
1-10
1-8
2 SY Frame
2-4 (Claw)
2-1
(DSC-H9 only)
2-2 (#12)
2-3 (#12)
4 Lens Block Assy
4-1(#74)
4-2(#74)
4-3(#74)
3 CCD Block Assy
3-1(#73)
