Sony DSC-H7 - ELECTRICAL PARTS LIST

Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DSC-H7/H9_L2
5-10
Note: Be sure to read “Precautions for Replacement of
Imager” on page 4-2 when changing the imager.
(Not supplied) CD-703 FLEXIBLE BOARD
*********************
(CD-703 board and IC003 are not supplied, but this is included in CCD
BLOCK ASSY.)
< CAPACITOR >
C001 1-164-943-81 CERAMIC CHIP 0.01UF 10% 16V
C003 1-100-505-11 CERAMIC CHIP 0.1UF 20% 16V
C005 1-125-777-11 CERAMIC CHIP 0.1UF 10% 10V
C006 1-107-826-11 CERAMIC CHIP 0.1UF 10% 16V
C007 1-164-943-81 CERAMIC CHIP 0.01UF 10% 16V
C008 1-164-943-81 CERAMIC CHIP 0.01UF 10% 16V
C009 1-100-505-11 CERAMIC CHIP 0.1UF 20% 16V
C010 1-164-943-81 CERAMIC CHIP 0.01UF 10% 16V
< IC >
IC003 (Not supplied) IC ICX636LQP-13
IC004 8-753-275-39 IC CXA3741UR-T9
< RESISTOR >
R003 1-218-985-11 RES-CHIP 470K 5% 1/16W
R006 1-218-990-81 CONDUCTOR, CHIP (1005)
R007 1-218-986-11 RES-CHIP 560K 5% 1/16W
R008 1-220-212-11 RES-CHIP 300K 5% 1/16W
R009 1-218-982-11 RES-CHIP 270K 5% 1/16W
A-1251-455-A CK-179 BOARD, COMPLETE (H9)
***********************
< CAPACITOR >
C001 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C002 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C003 1-119-923-11 CERAMIC CHIP 0.047UF 10% 10V
C004 1-125-891-11 CERAMIC CHIP 0.47UF 10% 10V
C005 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C006 1-125-777-11 CERAMIC CHIP 0.1UF 10% 10V
C007 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C008 1-112-300-91 CERAMIC CHIP 4.7UF 10% 10V
C009 1-100-966-91 CERAMIC CHIP 4.7UF 10% 10V
C010 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C011 1-165-989-11 CERAMIC CHIP 10UF 10% 6.3V
C012 1-100-966-91 CERAMIC CHIP 10UF 20% 10V
C014 1-125-777-11 CERAMIC CHIP 0.1UF 10% 10V
< CONNECTOR >
* CN001 1-821-248-11 CONNECTOR, FPC (ZIF) 39P
* CN002 1-816-959-51 FFC/FPC CONNECTOR (ZIF) 28P
< COIL >
L001 1-400-588-11 INDUCTOR, CHIP 10UH (2012)
L002 1-400-588-11 INDUCTOR, CHIP 10UH (2012)
< RESISTOR >
R004 1-218-946-11 RES-CHIP 270 5% 1/16W
R005 1-218-946-11 RES-CHIP 270 5% 1/16W
A-1251-445-A CK-180 BOARD, COMPLETE (H7)
***********************
< CAPACITOR >
C002 1-112-298-91 CERAMIC CHIP 1UF 10% 16V
C003 1-112-298-91 CERAMIC CHIP 1UF 10% 16V
C004 1-112-298-91 CERAMIC CHIP 1UF 10% 16V
C005 1-112-298-91 CERAMIC CHIP 1UF 10% 16V
C006 1-112-298-91 CERAMIC CHIP 1UF 10% 16V
C007 1-100-670-11 CERAMIC CHIP 4.7UF 20% 16V
C008 1-112-298-91 CERAMIC CHIP 1UF 10% 16V
C010 1-100-670-11 CERAMIC CHIP 4.7UF 20% 16V
C011 1-112-298-91 CERAMIC CHIP 1UF 10% 16V
C012 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C013 1-100-591-91 CERAMIC CHIP 1UF 10% 25V
C015 1-165-989-11 CERAMIC CHIP 10UF 10% 6.3V
C016 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
< CONNECTOR >
* CN001 1-817-544-71 CONNECTOR, FPC (ZIF) 39P
* CN002 1-816-959-51 FFC/FPC CONNECTOR (ZIF) 28P
< DIODE >
D003 6-500-813-01 DIODE MA2SD32008S0
< COIL >
L002 1-400-588-11 INDUCTOR 10UH
< RESISTOR >
R002 1-218-965-11 RES, CHIP 10K 5% 1/16W
R004 1-218-989-11 RES, CHIP 1M 5% 1/16W
A-1251-453-A CK-181 BOARD, COMPLETE (H7)
***********************
< CONNECTOR >
CN001 1-778-596-21 CONNECTOR, BOARD TO BOARD 30P
A-1251-460-A CK-182 BOARD, COMPLETE (H9)
***********************
< CONNECTOR >
CN001 1-778-596-21 CONNECTOR, BOARD TO BOARD 30P
1-871-941-11 DC-107 FLEXIBLE BOARD
*********************
< JACK >
0 J001 1-817-331-11 DC JACK 5P (DC IN)
Electrical parts list of DD-272 board are not shown.
Pages 5-11 to 5-12 is not shown.
• Refer to page 5-1 for mark 0.
DC-107CK-182CK-181CK-180CK-179CD-703
