Ref. No. Part No. Description Ref. No. Part No. Description
DSC-H7/H9_L2
5-13
1-871-952-11 DD-273 FLEXIBLE BOARD
*********************
0 A-1251-450-A JK-338 BOARD, COMPLETE
**********************
< CONNECTOR >
CN001 (Not supplied) CONNECTOR, MULTIPLE (SOCKET)
< LINE FILTER >
LF001 1-456-583-11 COMMON MODE CHOKE COIL
A-1251-448-A MS-364 BOARD, COMPLETE (H7)
***********************
< CAPACITOR >
C301 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C302 1-125-777-11 CERAMIC CHIP 0.1UF 10% 10V
C303 1-125-777-11 CERAMIC CHIP 0.1UF 10% 10V
C304 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN301 1-816-646-51 FFC/CONNECTOR, FPC (LIF) 16P
* CN302 1-819-990-21 MEMORY STICK DUO CONNECTOR 10P
< DIODE >
D301 6-501-216-01 DIODE CL-271HR-C-TS (ACCESS)
D302 6-500-813-01 DIODE MA2SD32008S0
< FERRITE BEAD >
FB305 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
< TRANSISTOR >
Q301 6-550-576-01 TRANSISTOR SSM6E01TU
< RESISTOR >
R301 1-218-947-11 RES-CHIP 330 5% 1/16W
R302 1-218-990-81 CONDUCTOR, CHIP 0
R303 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R304 1-218-985-11 RES-CHIP 470K 5% 1/16W
R305 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R306 1-218-953-11 RES-CHIP 1K 5% 1/16W
R307 1-218-990-81 CONDUCTOR, CHIP 0
R308 1-218-940-11 RES-CHIP 82 5% 1/16W
R309 1-218-940-11 RES-CHIP 82 5% 1/16W
R310 1-218-940-11 RES-CHIP 82 5% 1/16W
R311 1-218-940-11 RES-CHIP 82 5% 1/16W
R312 1-218-990-81 CONDUCTOR, CHIP 0
R313 1-218-938-11 RES-CHIP 56 5% 1/16W
R314 1-469-580-11 FERRITE 0UH
R315 1-469-580-11 FERRITE 0UH
R316 1-469-580-11 FERRITE 0UH
R317 1-469-580-11 FERRITE 0UH
R318 1-218-939-11 RES-CHIP 68 5% 1/16W
1-871-944-11 MS-365 FLEXiBLE BOARD
*********************
A-1251-458-A MS-366 BOARD, COMPLETE (H9)
***********************
< CAPACITOR >
C301 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C302 1-125-777-11 CERAMIC CHIP 0.1UF 10% 10V
C303 1-125-777-11 CERAMIC CHIP 0.1UF 10% 10V
C304 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN301 1-816-646-51 FFC/CONNECTOR, FPC (LIF) 16P
* CN302 1-819-990-21 MEMORY STICK DUO CONNECTOR 10P
< DIODE >
D301 6-501-216-01 DIODE CL-271HR-C-TS (ACCESS)
D302 6-500-813-01 DIODE MA2SD32008S0
< FERRITE BEAD >
FB305 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
< TRANSISTOR >
Q301 6-550-576-01 TRANSISTOR SSM6E01TU
< RESISTOR >
R301 1-218-947-11 RES-CHIP 330 5% 1/16W
R302 1-218-990-81 CONDUCTOR, CHIP 0
R303 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R304 1-218-985-11 RES-CHIP 470K 5% 1/16W
R305 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R306 1-218-953-11 RES-CHIP 1K 5% 1/16W
R307 1-218-990-81 CONDUCTOR, CHIP 0
R308 1-218-940-11 RES-CHIP 82 5% 1/16W
R309 1-218-940-11 RES-CHIP 82 5% 1/16W
R310 1-218-940-11 RES-CHIP 82 5% 1/16W
R311 1-218-940-11 RES-CHIP 82 5% 1/16W
R312 1-218-990-81 CONDUCTOR, CHIP 0
R313 1-218-938-11 RES-CHIP 56 5% 1/16W
R314 1-469-580-21 FERRITE 0UH
R315 1-469-580-21 FERRITE 0UH
R316 1-469-580-21 FERRITE 0UH
R317 1-469-580-21 FERRITE 0UH
R318 1-218-939-11 RES-CHIP 68 5% 1/16W
A-1251-447-A PL-046 BOARD, COMPLETE (H7)
**********************
(RY201 is not included in the PL-046 complete board.)
< CAPACITOR >
C201 1-165-908-11 CERAMIC 1uF 10% 10V
< CONNECTOR >
* CN201 1-817-554-51 CONNECTOR, FFC/FPC 6P
PL-046MS-366MS-365MS-364JK-338DD-273
• Refer to page 5-1 for mark 0.
