Sony DSC-H7 - Page 65

Ref. No. Part No. Description Ref. No. Part No. Description
DSC-H7/H9_L2
5-14
< DIODE >
D201 8-719-056-23 DIODE MA2S111-(K8).SO
< PLUNGER >
0RY201 1-455-038-11 SOLENOID, PLUNGER (Note)
< SWITCH >
S201 1-786-179-31 SWITCH, PUSH (1KEY) (STRB-POPUP)
A-1251-457-A PL-047 BOARD, COMPLETE (H9)
**********************
(RY201 is not included in the PL-047 complete board.)
< CAPACITOR >
C201 1-165-908-11 CERAMIC 1uF 10% 10V
< CONNECTOR >
* CN201 1-817-554-51 CONNECTOR, FFC/FPC 6P
< DIODE >
D201 8-719-056-23 DIODE MA2S111-(K8).SO
< PLUNGER >
0RY201 1-455-038-11 SOLENOID, PLUNGER (Note)
< SWITCH >
S201 1-786-179-31 SWITCH, PUSH (1KEY) (STRB-POPUP)
A-1256-815-A PW-134 BOARD, COMPLETE (SERVICE) (H7)
A-1256-816-A PW-134 BOARD, COMPLETE (SERVICE) (H9)
********************************
< CAPACITOR >
C001 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
< DIODE >
D001 6-500-512-01 DIODE CL-330IRS-X-TU (NIGHTSHOT) (H9)
D002 6-501-524-01 DIODE DOR5099
(AF ILLUMINATOR/SELF-TIMER)
D003 6-501-030-01 DIODE SML-412MWT86 (POWER)
< IC >
IC001 6-600-163-01 IC RS-770
< RESISTOR >
R001 1-216-825-11 METAL CHIP 2.2K 5% 1/10W (H9)
R014 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R015 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R016 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R017 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R018 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R019 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R020 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R021 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R022 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R023 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
< SWITCH >
S001 1-786-157-11 TACTILE SWITCH (POWER)
S003 1-786-157-11 TACTILE SWITCH (
z
) (H9)
S004 1-786-157-11 TACTILE SWITCH (
/ BRK
) (H9)
S005 1-798-036-21 ROTARY SWITCH (MODE DIAL)
S006 1-786-602-11 SWITCH, TACTILE (SHUTTER)
1-871-937-11 PY-002 FLEXIBLE BOARD
*********************
(S001 and S002 are not supplied. But they are included in te PY-002 flexible board.)
< SWITCH >
S001 (Not supplied) SWITCH (
B
) (Note)
S002 (Not supplied) SWITCH (FINDER/LCD) (Note)
0 A-1251-449-A ST-166 BOARD, COMPLETE
**********************
(FL901 is not included in the ST-166 complete board.)
< CAPACITOR >
* C002 1-112-832-21 CERAMIC CHIP 0.033uF 10% 250V
< FLASH UNIT >
0 FL901 1-481-062-11 FLASH UNIT (Note)
< COIL >
0 L001 1-456-193-11 COIL, TRIGGER
< RESISTOR >
R001 1-216-121-11 RES-CHIP 1M 5% 1/10W
A-1251-456-A SW-499 BOARD, COMPLETE (H9)
***********************
< CONNECTOR >
CN101 1-816-684-51 CONNECTOR, FFC/FPC (ZIF) 8P
* CN102 1-817-554-51 CONNECTOR, FFC/FPC 6P
* CN103 1-817-554-51 CONNECTOR, FFC/FPC 6P
< DIODE >
D101 6-500-776-01 DIODE MAZW068H0LS0
D104 8-719-056-54 DIODE MAZS068008SO
< RESISTOR >
R101 1-218-964-11 RES-CHIP 8.2K 5% 1/16W
R102 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R103 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R104 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R105 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
• Refer to page 5-1 for mark 0.
SW-499ST-166PY-002PW-134PL-047PL-046
