Ref. No. Part No. Description Ref. No. Part No. Description
DSC-H7/H9_L2
5-15
< SWITCH >
S101 1-786-819-22 TACTILE SWITCH (ZOOM T)
S102 1-786-819-22 TACTILE SWITCH (ZOOM W)
S103 1-786-157-11 TACTILE SWITCH (MENU)
S104 1-786-157-11 TACTILE SWITCH (HOME)
A-1251-446-A SW-500 BOARD, COMPLETE (H7)
***********************
< CONNECTOR >
CN101 1-816-684-51 CONNECTOR, FFC/FPC (ZIF) 8P
* CN102 1-817-554-51 CONNECTOR, FFC/FPC 6P
* CN103 1-817-554-51 CONNECTOR, FFC/FPC 6P
< DIODE >
D101 6-500-776-01 DIODE MAZW068H0LS0
D104 8-719-056-54 DIODE MAZS068008SO
< RESISTOR >
R101 1-218-964-11 RES-CHIP 8.2K 5% 1/16W
R102 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R103 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R104 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R105 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
< SWITCH >
S101 1-786-819-22 TACTILE SWITCH (ZOOM T)
S102 1-786-819-22 TACTILE SWITCH (ZOOM W)
S103 1-786-157-11 TACTILE SWITCH (MENU)
S104 1-786-157-11 TACTILE SWITCH (HOME)
1-872-388-11 SW-504 FLEXIBLE BOARD
*********************
Electrical parts list of SY-177 board are not shown.
Pages 5-16 to 5-19 is not shown.
SW-500SW-499 SW-504
