Sony DSC-H7 - Page 15

2-3
DSC-H7/H9_L2
HARDWARE LIST
HARDWARE LIST
EXPLODED VIEW
EXPLODED VIEW
2-1-2. CABINET(REAR) BLOCK ASSY AND JK-338 FLEXIBLE BOARD (DSC-H9)
1 Cabinet (Rear) Block ASSY
1-1 (#10)
1-2
1-3
1-4
1-5 (#12)
1-6 (#10)
1-7 (#10)
1-8 (#10)
1-9 (#10)
1-10 (#10)
1-11
1-13
1-12
2 JK-338 Flexible Board
2-1(#10)
2-3
2-4
2-2
1-14
Note: High-voltage cautions
Discharging the Capacitor
Short-circuit between the two points
with the short jig about 10 seconds.
R:1 kΩ/1 W
(Part code: 1-215-869-11)
