DSC-M1
HELP
HELP 02
2
1
5
1
LCD hinge assembly
2
FP-038 flexible board
3
3
Twist the FP-038 flexible board.
4
Twist the FP-038 flexible board.
5
Hinge adhesive sheet (upper)
6
FP-038 flexible board (31P)
4
6
Note: Be very careful not to
damage the flexible board.
Note: Be very careful not to
damage the flexible board.
Note: Be very careful not to
damage the flexible board.
Caution
Note : The sheet cannot be reused.
To Next Page
