Sony DSC-M1 - Is Not Shown; Waveforms of the SY-114 Board Are Not Shown

4-61
DSC-M1
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
4-4. WAVEFORMS
PM-045
Waveforms of the SY-114 board are not shown.
Page 4-62 is not shown.
PM-045 BOARD
V
2.9 Vp-p
1 IC201 1
H
3.2 Vp-p
2 IC201 w;
H
3.2 Vp-p
3 IC201 wa
H
3.2 Vp-p
4 IC201 ws
H
4.2 Vp-p
5 IC201 wh
H
380 mVp-p
6 IC201 es
H
420mVp-p
7 IC201 ed
H
500 mVp-p
8 IC201 ef
H
2.9 Vp-p
9 IC201 rk
