DSC-M1
Ref. No. Part No. Description Ref. No. Part No. Description
A-1081-824-A PM-045 BOARD, COMPLETE
***********************
(Ref. No.; 4,000 Series)
< CAPACITOR >
C202 1-125-839-91 TANTAL. CHIP 47uF 20% 6.3V
C203 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C206 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C207 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C208 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C209 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C210 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C211 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C212 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C213 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C215 1-100-671-11 CERAMIC CHIP 4.7uF 20% 25V
C217 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C218 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C223 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C224 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C225 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C226 1-164-878-11 CERAMIC CHIP 150PF 5% 50V
C227 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C301 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C302 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C303 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C305 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C307 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C311 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C312 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C313 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C314 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C315 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C316 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C317 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C318 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C319 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C320 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C321 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C322 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C324 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C325 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN201 1-691-362-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN202 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN203 1-691-370-11 CONNECTOR, FFC/FPC 6P
CN204 1-816-688-31 CONNECTOR, FPC (ZIF) 29P
CN301 1-794-375-21 PIN, CONNECTOR 2P
CN302 1-794-375-21 PIN, CONNECTOR 2P
< DIODE >
D202 6-500-941-01 DIODE MAZS056008S0
< FERRITE BEAD >
FB201 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
< IC >
IC201 8-752-109-72 IC CXM3006R
IC301 8-759-679-11 IC BH7870AKV-E2
< COIL >
L202 1-469-846-11 INDUCTOR 47uH
L204 1-469-570-11 INDUCTOR 10uH
L213 1-469-846-11 INDUCTOR 47uH
L301 1-469-528-91 INDUCTOR 100uH
< TRANSISTOR >
Q203 6-550-119-01 TRANSISTOR DTC144EMT2L
Q204 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q205 8-759-054-48 TRANSISTOR UP04601008SO
< RESISTOR >
R203 1-218-975-11 RES-CHIP 68K 5% 1/16W
R204 1-218-949-11 RES-CHIP 470 5% 1/16W
R205 1-208-934-11 METAL CHIP 91K 0.5% 1/16W
R206 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R207 1-218-990-11 SHORT CHIP 0
R209 1-218-990-11 SHORT CHIP 0
R210 1-218-990-11 SHORT CHIP 0
R211 1-218-965-11 RES-CHIP 10K 5% 1/16W
R212 1-218-929-11 RES-CHIP 10 5% 1/16W
R213 1-218-929-11 RES-CHIP 10 5% 1/16W
R214 1-218-929-11 RES-CHIP 10 5% 1/16W
R215 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R216 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R217 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R218 1-218-969-11 RES-CHIP 22K 5% 1/16W
R223 1-218-990-11 SHORT CHIP 0
R224 1-218-989-11 RES-CHIP 1M 5% 1/16W
R225 1-218-978-11 RES-CHIP 120K 5% 1/16W
R226 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R227 1-208-929-11 METAL CHIP 56K 0.5% 1/16W
R228 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R229 1-218-965-11 RES-CHIP 10K 5% 1/16W
R230 1-218-969-11 RES-CHIP 22K 5% 1/16W
R231 1-218-965-11 RES-CHIP 10K 5% 1/16W
R301 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R302 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R303 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R304 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R305 1-218-870-11 METAL CHIP 9.1K 0.5% 1/10W
R306 1-218-870-11 METAL CHIP 9.1K 0.5% 1/10W
R307 1-218-870-11 METAL CHIP 9.1K 0.5% 1/10W
R308 1-218-870-11 METAL CHIP 9.1K 0.5% 1/10W
R309 1-216-834-11 METAL CHIP 12K 5% 1/10W
R310 1-216-864-11 SHORT CHIP 0
R311 1-216-864-11 SHORT CHIP 0
