2-11E
DSC-P52
The flexible boards contained in the VIDEO LENS are not shown.
CONTROL SWITCH BLOC
K
(SW-392)
CONTROL SWITCH BLOCK
(RL-060)
UNIT PARTS (UA-003)
FP-643
JK BLOCK
(JK-256)
FP-689
2-12.FLEXIBLE BOARDS LOCATION
