— 2 —
DSC-P52
SECTION 1 SERVICE NOTE
• NOTICE FOR CCD BLOCK ASSY REPLACEMENT
[Remedy]
1. Confirm the resistor value of board.
SY-91 board (R356)
2. The repair method is different according to the register value of board.
(1) When the register value is 470KΩ.
It is not necessary to change the register value/data.
(2) When the register value is 1MΩ.
1) Change the register value of board to 470kΩ.
SY-91 board (R356) 1-218-989-11 (1MΩ) k 1-218-985-11 (470KΩ)
2) Change data too as follows.
Page
79
79
79
77
6F
Address
0C
10
11
70
04
1MΩ
Data
90
27
D8
0E
04
470KΩ
Data
92
40
00
10
11
k
: Changed portion
SECTION 5 REPAIR PARTS LIST
5-1. EXPLODED VIEWS
Page
IC351 A-7095-744-A CCD BLOCK ASSY (CCD IMAGER)IC351 A-7016-308-A CCD BLOCK ASSY (CCD IMAGER)
Ref. No. Part No. DescriptionRef. No. Part No. Description
Before change After change
5-5
5-1-3. LENS FRAME BLOCK ASSEMBLY
