If the screw is sticking out of the frame, loosen the screw.
3. While holding the eyepiece between your fingers, insert the eyepiece cup into the
eyepiece.
Insert the eyepiece cup until it pops in.
4. Tighten the screw to lock the eyepiece cup in place.
To remove the eyepiece cup
Loosen the eyepiece cup screw and remove the eyepiece cup.
Note
When the eyepiece cup is attached, the viewfinder cannot be stored.
Do not push down the viewfinder with the eyepiece cup attached. The camera or the
eyepiece cup may be damaged.
When the eyepiece cup is attached, some accessories cannot be attached.
[10] How to Use
Before Use Adjusting the viewfinder
Adjusting the viewfinder (diopter-adjustment)
Adjust the diopter scale to your eyesight until the display appears clearly in the viewfinder.
