Sony DSR-570WSP User Manual

2-28
DSR-570WS/570WSP V1
Panel display Connecting connector
WRR 1-569-200-11
(7P, FEMALE) CONNECTOR, 7P, MALE
BATTERY 1-784-815-11
(5P, MALE) PLUG, 5P, FEMALE
i.LINK. DV Cable (6P-4P) : CCFD-3L
DV Cable (6P-6P) : CCF-3L
2-12. Input/Output Signals of Connectors
Inputs
GENLOCK IN: BNC type
1.0 Vp-p, 75 Z, sync negative
TC IN: BNC type
0.5 to 18 Vp-p, 10 kZ
AUDIO 1/2 IN: XLR 3P
_ 60 dBu, Zi > 3 kZ / + 4 dBu,
10 kZ balanced
Outputs
MONITOR OUT: BNC type
VIDEO OUT: BNC type
1.0 Vp-p, 75 Z, sync negative
TC OUT: BNC type
1.0 Vp-p, 75 Z
EAR PHONE: _∞ to _15.5 dBu variable, 8 Z
(Stereo mini jack)
AUDIO 1/2: RCA PIN _10 dBu, 47 kZ
i.LINK: 6P, IEEE 1394
2-11. Connecting Connectors
When connecting cables to connectors in installation and
servicing, attach the following connectors or equivalent
product to the tip of the cables.
Panel display Connecting connector
CH-1/CH-2 1-508-084-00
AUDIO IN (+48 V) CONNECTOR, XLR 3P, MALE
DC IN 1-508-362-00
CONNECTOR, XLR 4P, FEMALE
TC IN/OUT 1-560-069-11
CONNECTOR, BNC, MALE
GENLOCK IN 1-560-069-11
CONNECTOR, BNC, MALE
MONITOR OUT 1-560-069-11
CONNECTOR, BNC, MALE
EAR PHONE PLUG, MINI, STEREO
DC OUT (+12 V) 1-566-425-11
PLUG, 4P, MALE
CH-1/CH-2 1-506-311-00
AUDIO OUT RCA PIN, MALE
S-VIDEO OUT S-VIDEO
CONNECTOR CABLE
(Option): YC-30 V (3 m)
YC-15 V (1.5 m)
REMOTE 1-506-522-11
(10P, FEMALE) CONNECTOR, ROUND 10P, MALE
HIROSE HR 10A-10P-10P or equivalent or
CCA-7-20 Cable assembly (Sold separately)
VIDEO OUT 1-560-661-11
(BNC) PLUG, BNC
LENS 1-564-360-11
(12P, FEMALE) CONNECTOR, 12P, MALE
HIROSE HR 10-10PA-12P or equivalent
MIC 1-508-084-31
(3P, FEMALE) CONNECTOR, 3P, MALE
CANNON XLA-3-12C or equivalent
VF 1-778-661-11
(20P, FEMALE) CONNECTOR, 20P, MALE
HIROSE HR 12-14PA-20PC or equivalent
VTR/CCU 1-564-184-21
(26P, MALE) PLUG, CONNECTOR (SOCKET)
26P FEMALE
. For 14P-VTR use
CCZQ-A2 (2 m)
CCZQ-A5 (5 m)
CCZQ-A10 (10 m)
. For 26P-VTR use
CCZ-A2 (2 m)
CCZ-A5 (5 m)
CCZ-A10 (10 m)
CCZ-A25 (25 m)
*
CCZ-A50 (50 m)
*
CCZ-A100 (100 m)
*
* : When CCU is connected

Sony DSR-570WSP Specifications

General

Sensor Type	3 CCD
Optical Zoom	12x
Focus	Auto/Manual
Viewfinder	Color LCD
Recording System	DVCAM
Image Device	1/2 inch
Lens Mount	Bayonet
Zoom	12x optical
Shutter Speed	1/10000 sec
Recording Media	DVCAM
Input/Output	Composite, S-Video
Power Supply	DC 12V
Type	Professional Camcorder
Audio Recording	48kHz/16-bit (2ch), 32kHz/12-bit (4ch)
Audio	2-channel, 4-channel
