DSR-PD170/PD170P/PD190P
2-4. FK-088, MA-430D, RM-091, XD-003, XS-004, XM-005, XZ-003 BOARDS
1 RM-091
board (21P)
3 MA-430D
board (23P)
2 Sheet
4 Ferrite
core
7 FK-088 board
5 Three screws
(M2 × 5),
spring bolt
8 FK frame
assembly
9 Cabinet (upper)
6 Four screws
(M2
× 3),
spring bolt
6 XZ-003
board
qs FP-897 flexible
board (21P)
3 Tapping
screw (B2
× 5)
7 Tapping
screw
(B2
× 5)
5 RM-091
board (7P)
q; RM-091 boar
d
8 Two claws
9 RM fixed
holder assembly
1 Three screws
(M2 × 5),
lock ace
2 Four tapping
screws (B2
× 5)
qd MA-430D board
qa Screw (M2 × 3),
lock ace
2 Microphone holder
assembly
w; Handle (D) assembly
4 Handle cover
(D) assembly
4 Two screws
(M2 × 5), lock ace
qg Three Tapping screws
(M2 × 5)
3 Three screws
(M2
× 5), lock ace
6 Four screws
(M2.6)
7 Screw (M2.6)
qd Screw (M2 × 3),
lock ace
qa Handle cabinet (R)
8 Cable holder
qh Two tapping screws (B2 × 5)
qf XD-003 board,
DD bracket
0 XM-005 board,
XLR sheet metal
Remove the XM-005 board
and XLR sheet metal in the
direction of the arrow.
qk XS-004 board,
FP-897 flexible board
ql Handle cabinet (L)
assembly
qs FP-218 flexible
board (13P)
5 Two FP-217 flexible
boards (16P)
qj SW insulated plate
1 Two screws
(B3 × 10)
A
A
PRECAUTION DURING INSTALLATION
9
When installing it, align the five switch
positions as arrow.
