DSR-PD170/PD170P/PD190P
SPECIFICATIONS
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH
MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0 SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
CAUTION :
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
AC Adaptor
AC-L15A/L15B
Power requirements
100 - 240 V AC, 50/60 Hz
Current consumption
0.35 - 0.18 A
Power consumption
18 W
Output voltage
DC OUT: 8.4 V, 1.5 A
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Dimensions (approx.)
56 × 31 × 100 mm
(2 1/4 × 1 1/4 × 4 in) (w/h/d)
excluding projecting parts
Mass (approx.)
190 g (6.7 oz)
excluding power cord
Rechargeable battery
pack NP-F330
Output voltage
DC 7.2 V
Capacity
5.0 Wh
Dimensions (approx.)
38.4 × 20.6 × 70.8 mm (1 9/16 ×
13/16 × 2 7/8 in) (w/h/d)
Mass (approx.)
70 g (2.5 oz)
Type
Lithium ion
Wide conversion lens
VCL-HG0758
Lens power
0.7
Lens structure
3 groups, 3 elements
Screw thread for video camera
recorder
M58 × 0.75
Dimensions
Maximum diameter : ø 93 mm (3
3/4 in)
Length : Approx. 48 mm (1 15/16 in)
Mass (excluding the caps)
Approx. 418 g (14 oz)
Supplied accessories
Lens caps (2) (for the front and
back of the lens)
Carrying pouch (1)
Design and specifications are
subject to change without notice.
VIDEO input/output
Input/output auto switch
RCA pin-jack, 1 Vp-p, 75 ohms,
unbalanced
AUDIO CH1/CH2 input/output
Input/output auto switch
RCA pin-jack, 327 mV, (at output
impedance more than 47 kilohms)
Output impedance with less than
2.2 kilohms
Input impedance more than
47 kilohms
Headphones jack
Stereo minijack (ø 3.5 mm)
LANC control jack
Stereo mini-minijack (ø 2.5 mm)
INPUT1/INPUT2 connectors
XLR 3-pin, female, –60 dBu:
3 kilohms, +4 dBu: 10 kilohms
(0 dBu = 0.775 Vrms)
DV Interface
4-pin connector
Speaker
Dynamic speaker (ø 20 mm)
LCD screen
6.2 cm (2.5 type)
Total dot number
211 000 (960 × 220)
General
Power requirements
7.2 V (battery pack)
8.4 V (AC Adaptor)
Average power consumption
(when using the battery pack)
During camera recording using
LCD
5.4 W
Viewfinder
4.7 W
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Dimensions (approx.)
133 × 180 × 456 mm (5 1/4 × 7 1/8
× 18 in) (w/h/d)
Mass (approx.)
1.6 kg (3 lb 9 oz)
including the hood with a lens
cap
1.7 kg (3 lb 12 oz)
including the NP-F330
rechargeable battery pack, cassette
PDVM-40ME and microphone
Supplied accessories
See page 5-39.
Video camera
recorder
System
Video recording system
2 rotary heads
Helical scanning system
Audio recording system
Rotary heads, PCM system
Quantization: Fs32 kHz (12 bits,
channels 1/2, channels 3/4),
Fs48 kHz (16 bits, channels 1/2)
V
DSR-PD170:
DSR-PD170P/PD190P:
ideo signal
NTSC color, EIA standards
Usable cassette
Mini DVCAM cassette with the
mark printed
Mini DV cassette with the
mark printed
Tape speed
DVCAM format:
Approx. 28.218 mm/s
DV format SP mode: Approx.
18.812 mm/s
Recording/playback time (using
cassette PDVM-40ME)
DVCAM format: 40 min
DV format SP mode: 1 h
Fast-forward/rewind time
(using cassette PDVM-40ME)
Approx. 2 min and 30 s
Viewfinder
Electric viewfinder (B&W)
Image device
1/3 type CCD (3 Charge Coupled
Device)
Approx. 380 000 pixels
(Effective: Approx. 340 000 pixels)
Lens
Combined power zoom lens
Filter diameter 58 mm (2 3/8 in)
12× (Optical), 48× (Digital)
F1.6 - 2.4
Focal length
6 - 72 mm (1/4 - 2 7/8 in)
When converted to a 35 mm still
camera
43.2 - 518.4 mm (1 3/4 - 20 1/2 in)
Color temperature
Auto, n
Indoor (3 200 K),
Outdoor (5 800 K),
Minimum illumination
1 lux (F1.6)
Input/Output connectors
S VIDEO input/output
Input/output auto switch
4-pin mini DIN
Luminance signal: 1 Vp-p,
75 ohms, unbalanced
Chrominance signal: 0.286 Vp-p,
75 ohms, unbalanced
PAL colour, CCIR standards
DSR-PD170:
DSR-PD170P/PD190P:
Approx. 450 000 pixels
(Effective: Approx. 400 000 pixels)
DSR-PD170:
DSR-PD170P/PD190P:
Chrominance signal: 0.3 Vp-p, 75
ohms, unbalanced
Peak inrush current
Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
6.3 A (230 V)
(DSR-PD170P/PD190P)
To Next Page
