6-2
DVP-FX921/FX921K/FX930/FX930CC/FX930WM/FX935
Pin No. Name I/O Description
54 DVDSD18 - 1.8V power pin for internal digital circuitry
55 DQM0 I/O PD data mask 0
56 RD15 I/O DRAM data 15
57 RD14 I/O DRAM data 14
58 RD13 I/O DRAM data 13
59 RD12 I/O DRAM data 12
60 DVSS33 - 3.3V Ground pin for internal digital circuitry
61 RD11 I/O DRAM data 11
62 RD10 I/O DRAM data 10
63 RD9 I/O DRAM data 9
64 RD8 I/O DRAM data 8
65 DQM1 I/O PD data mask 1
66 RCLK I/O DRAM clock
67 RA11 I/O DRAM address bit 11
68 DVDD33 - 3.3V power pin for internal digital circuitry
69 RA9 I/O PD DRAM address 9
70 RA8 I/O PD DRAM address 8
71 RA7 I/O PD DRAM address 7
72 RA6 I/O PD DRAM address 6
73 RA5 I/O PD DRAM address 5
74 RA4 I/O PD DRAM address 4
75 RWE# O PD DRAM write enable, active low
76 CAS# O PD DRAM column address strobe, active low
77 RAS# O PD DRAM row address strobe, active low
78 BA0 I/O PD DRAM bank address 0
79 DVSS18 - 1.8V ground pin for internal digital circuitry
80 BA1 I/O PD DRAM bank address 1
81 RA10 I/O PD DRAM address 10
82 RA0 I/O PD DRAM address 0
83 RA1 I/O PD DRAM address 1
84 DVDD33 - 3.3V power pin for internal digital circuitry
85 RA2 I/O PD DRAM address 2
86 RA3 I/O PD DRAM address 3
87 GPIO7/CKE I/O Microcontroller port 1-4 (Internal pull-Up)
88 VSTD/GPIO8 I/O Microcontroller port 1-5 (Internal pull-Up)
89 UD/GPIO9 I GPIO9
90 DVDD18 - 1.8V power pin for internal digital circuitry
91 LR/GPIO10 O GPIO10
92 HSTR/GPIO11 I/O GPIO11
93 SPDIF/GPIO12 O GPIO12
94 VSYU/GPIO13 I GPIO13
95 VCK/GPIO14 I/O 3.3V power pin for video DAC circuitry
96 VOE/GPIO15 I Bandgap reference voltage
97 HOE/GPIO16 - Full scale adjustment (suggest to use 560 ohm)
98 HSTL/GPIO17 I Ground pin for video DAC circuitry
99 HCK/GPIO18 I/O Analog composite output
100 DACVDDC - 3.3V power pin for video DAC circuitry
101 VREF O 3.3V power pin for video DAC circuitry
102 FS O Green, Y, SY, or CVBS
103 DACVSSC - Blue, CB/PB, or SC
104 CVBS O Red, CR/PR, CVBS, or SY
105 DACVDDB - Analog ground pin
106 DACVDDA - HSYN/VSYN output
107 Y O Y single output
