6-3E
DVP-FX921/FX921K/FX930/FX930CC/FX930WM/FX935
Pin No. Name I/O Description
108 C O C single output
109 CVBS O 3.3V power pin
110 AADVSS - 3.3V power pin for audio clock circuitry
111
AKIN2/GPIO19/
AUDIO_MUTE
O APLL external capacitance connection
112
ADVCM/GPIO20/
VCOM
I Ground pin for audio DAC circuitry
113
AKIN1/GPIO21/
AUDIO_MUTE
I Ground pin for audio DAC circuitry
114 AADVDD - Reserved
115 APLLVDD - Reserved
116 APLLCAP O GPIO
117 ADACVSS - Audio DAC reference voltage
118 AR/GPIO0 O Audio DAC right channel output
119 AVCM O Reserved
120 AL/GPIO1 O Audio DAC left channel output
121 ADACVDD1 - 3.3V power pin for audio DAC circuitry
122 ADACVDD2 - 3.3V power pin for audio DAC circuitry
123 AVDD18 - Analog 1.8V power
124 AGND18 - Analog ground
125 RFIP I AC coupled DVD RF signal input RFIP
126 RFIN/OPOUT I AC coupled DVD RF signal input RFIN
127 RFG/OPINP I Main beam, RF AC input path
128 RFH/OPINN I Main beam, RF AC input path
