DVP-FX97/FX980/FX980WM
1-2
1-3.

TRAVERSE UNIT/ MAIN BOARD/ BATTERY
②
traverse unit
②
battery
①
two screws
(TS2 x 6.5)
②
connector
③ IO support
④
main board
⑤ IO support
①
FFC
①
connector
[NOTE
]
When reassembling the main board,
make sure the position of the slide
switch and knob.
1-4.

UPPER BLOCK (1/2)
②
two screws (MS2.5 x 6.5)
①
connector
③ LCD panel block
