8-2
DVP-NS30/NS32/NS33/NS52P
1 3-089-692-01 CASE, UPPER BLACK
1 3-089-692-21 CASE, UPPER SILVER
2 3-070-883-31 SCREW, TAPPING BLACK
2 3-070-883-41 SCREW, TAPPING SILVER
3 3-077-331-11 +BV3 (3-CR)
4 3-077-331-21 +BV3 (3-CR)
5 X-2055-448-1 COVER ASSY,TRAY (NS52P)
6 3-088-489-01 INSULATOR, PS
7 1-828-450-11 POWER-SUPPLY CORD (NS30:AEP,RUS/
NS32:AEP,RUS/NS33/NS52P:AEP,RUS)
7 1-828-454-11 POWER-SUPPLY CORD (NS30:UK/NS52P:UK)
8 3-071-119-91 LID, BATTERY CASE
9 1-479-179-21 REMOTE COMMANDER (RMT-D175P)
10 X-2048-742-1 PANEL ASSY, FRONT (NS30:UK) BLACK
10 X-2050-620-1 PANEL ASSY,FRONT (NS52P) SILVER
10 X-2048-487-1 PANEL ASSY, FRONT (NS30) SILVER
10 X-2048-743-1 PANEL ASSY, FRONT (NS32) SILVER
10 X-2048-744-1 PANEL ASSY, FRONT (NS33) SILVER
10 X-2048-489-1 PANEL ASSY, FRONT (NS32) BLACK
12 A-1102-280-A MV-45 COMPLETE (NS30:AEP,UK)
12 A-1102-282-A MV-45 COMPLETE (NS30:RUS)
12 A-1102-286-A MV-45 COMPLETE (NS32:RUS)
12 A-1102-288-A MV-45 COMPLETE (NS33)
12 A-1102-290-A MV-45 COMPLETE (NS52P:AEP,UK)
12 A-1115-358-A MV-45 COMPLETE (NS32:AEP)
12 A-1121-394-A MV-45 COMPLETE (NS52P:RUS)
13 1-830-282-12 FLEXIBLE FLAT CABLE (FMD-004)
14 1-830-283-11 FLEXIBLE FLAT CABLE (FMS-003)
15 1-478-540-32 POWER SUPPLY BLOCK
16 1-830-284-11 FLEXIBLE FLAT CABLE (FEM-001)
Ref. No. Part No. Description Remark
Note :
The components identified
by mark or dotted line
with mark are critical for
safety.
Replace only with part
number specified.
Note :
Les composants identifiés par
une marque sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
