Sony Effio E - Lens Type; Shutter; AGC

Page11of27
3.1 Lens type
There are 2 types of lenses, respectively: DC lens (DC drive lens),
video camera (manual lens). Users can select the lens type according to
the using the camera. Press the "left" or "right" button on to choose the
lens. When select the auto iris, should choose "Auto" file; users can
adjust the "speed" value to adjust the open speed of auto iris. The value
smaller, the speed of opening the iris is lower; the value bigger, the
speed is faster.
3.2 Shutter / AGC
Move the cursor to "Shutter / AGC"; press the "OK" button to
enter the Shutter / AGC sub-menu. Shutter/AGC has two sub-menus:
"Automatic", "Manual". Press left-right key, and then press the Enter
key to enter sub-menu to set the relevant parameters.
AUTO IRIS
TYPE DC
MODE AUTO
SPEED 0--255
RETURN
