Sony Effio E - Adaptive Tone Reproduction (ATR); Motion Detection Zone Setup

Page15of27
3.6 Adaptive Tone Reproduction
The ATR (Adaptive Tone Reproduction) function provides
gradation compensation to improve the contrast of subjects whose
gradation has been lost in cases where, for instance, both
low-luminance areas and high-luminance areas exist in the same
picture.
Brightness and contrast values can be chose between the "low,
medium, high", User can choose an appropriate value to achieve the
best image quality.
3.7 Motion Zone Test
In the " Motion Zone Test " menu, press the "left" "right" to select
"On". At this point the image will open the motion detection. Then,
click "OK" button to enter the " Motion Zone Test" setting sub-menu,
to set the detect range and sensitivity settings.
A
TR
LUMINANCE LOW
CONTRAST LOW
RETURN
MOTION DET
DETECT SENSE 0-127
BLOCK DISP ON
MONITOR AREA ON
AREA SEL 1/4
TOP 0-288
BOTTOM 0-288
LEFT 0-468
RIGHT 0-468
RETURN
