IV、Technical Specification
Function
Imaging Sensor 1 / 3" Sony Effio E
Pixel
PAL：976（H）×582（V）；
NTSC：976（H）×494（V）
Signal System PAL/ NTSC
Syn. System Internal Synchronization
Shutter speed
PAL：1/50～1/100000s；
NTSC：1/60～1/100000s
S/N Ratio More than 50dB（AGC OFF）
Video Output 1.0Vp-p, 75 ohms
Horizontal resolution Color: 650TVL, B/W: 700TVL
Minimum Illumination
Color0.1Lux(F1.2,50IRE,AGC ON)
B/W:0.001Lux(F1.2,50IRE,AGC ON)
0 Lux when IR on
IR Leds (optional)
& IR distance
(1) 24pcs ф5mm IR LEDs: 20-25 meters;
(2) 36pcs ф5mm IR LEDs: 35-40 meters;
(2) 42pcs ф5mm IR LEDs: 35-40 meters;
(4) 72pcs ф5mm IR LEDs: 40-45 meters;
(4) 36pcs ф8mm IR LEDs: 45-50 meters;
(5) 12pcs power IR LEDs: 80-90 meters;
(6) wavelength of IR LED: 850nm
D/N Switch Auto/Color/B/W/External Control
Brightness Switch Color to B/W & B/W to Color for option
D/N Switching Time 0s～10s
Title setting 16 characters
Title Position Any position on the Screen
Image Brightness 0～99 adjustable
AGC Off/12db/24db/36db
OSD English/Chinese OSD
Peripheral Brightness
Compensation
0～50 adjustable
Strong Light Reversion 0～60 adjustable
