Setting
the
RF
Unit
41
;
oe
Specifications
1
Set
the
RF
UNIT
located
at
the
rear
to
3
CH
or
4
CH,
whichever
is
not
active
in
your
area.
To
get
the
proper
RF
signal,
set
the
RF
UNIT
selector
switch
on
the
rear
panel
of
the
EV-C3.
If
channel
4
is
active
in
your
area,
set
the
switch
to
channel
3,
and
vice
versa
2
Insert
a
recorded
cassette.
3 Press b PLAY.
4 Turn on the TV.
*
For
details
about
the
TV
channel
adjustment,
see
the
instruction
of
the
TV
receiver.
Set
the
TV
receiver
to
either
VHF
channel
3
or
4
to
agree
with
the
RF
UNIT
setting
you
in
step
1.
The
recorded
on
the
|
appear
on
the
TV
screen.
if
no
appears
on
the
screen,
or
if
the
display
is
not
clear,
fine-tune
the
channel
on
the TV.
Video
recording
system
Rotary
two-head
helical
scanning
FM
color
under
system
Video
signal
NTSG
color,
EIA
standards
Audio
recording
system
Rotary
head,
FM
system
Usable
cassettes 8
mm
format video
cassettes
Tape speed ‘SP mode: Approx. 14.3 mmisec.
LP
mode:
Approx.
7.2
mm/sec.
Recording/playback
time
SP
mode:
2
hours
with
the
Sony
P6-120MP
video
cassette
LP
mode:
4
hours
with
the
Sony
P6-120MP
video
cassette
Fast forwardirewind time
Approx.
4
min
with
the
Sony
P6-90MP video cassette
Inputs and Outputs
Video
input
VIDEO
IN:
phono
jack
1Vp-p,
75 ohms
unbalanced,
sync
negative
Video
output
VIDEO
OUT:
phono
jack
Wp-p,
75
ohms
unbalanced,
sync
negative
AUDIO IN:
phono
jack
-75
dBs
(0
dBs
=0.775
res)
Audio
output
AUDIO
OUT:
phono
jack
-75 dBs
Audio input
VHF/UHF
input
F-type
connector,
75
ohms,
‘unbalanced
VHF/UHF
output
F-type
connector,
75
ohms,
unbalanced,
VHF
channel
3
or
4
selectable
Controt
S
IN
Mini
type
Control
L
(Master/siave)
5
pin
DIN
General
Power
requirements
AC 120 V +10%, 60 Hz
Power
consumption
16 W
Operating
temperature
5°C to 40°C (41°F to 104°F)
Storage
temperature
~20°C
to
+60°C
(-4°F
to
+140°F)
;
,
Dimension
Approx.
178
x
88
x
255
mm
F
(7'le
x
342
=
10'fs
inches)
id)
including
the
projecting
parts
and
controls
Weight
Approx.
2.4
kg
(6
Ib.
5
02)
Remote
Commander
RMT-450
Remote
contro!
system
(Infrared
control
Command
mode
VTR:2
Power
requirments
3
V
OC,
using
two
size
AA
(R6)
batteries
Dimensions
Approx.
40
x
18
x
175
mm
(15's
x
344
x
7
inches)
(wihid)
including
projecting
parts
and
controls.
Weight
Approx.
105
g
(3.7
oz.)
(without
batteries)
Accessories
Supplied
Remote
Commander
RMT-450
(1)
Size
AA
(R6)
battery
(2)
External
antenna
connector
(1)
75-ohm
coaxial
cable
with
F-type
connector,
2
m
(1)
Design
and
specifications
are
subject
to
change
without
