Command List
FCB-EH6500(GB) A-EEP-100-11(1)
Digital Zoom Combine mode
Digital Zoom
Ratio
Digital Zoom
Position Data
×1 4000
×2 6000
×3 6A80
×4 7000
×5 7300
×6 7540
×7 76C0
×8 7800
×9 78C0
×10 7980
×11 7A00
×12 7AC0
Digital Zoom Separate mode
Digital Zoom
Ratio
Digital Zoom
Position Data
×1 00
×2 80
×3 AA
×4 C0
×5 CC
×6 D5
×7 DB
×8 E0
×9 E3
×10 E6
×11 E8
×12 EB
Lens control
Zoom Position
0000 to 4000 to 7AC0
Wide end Optical Digital
Tele end Tele end
Focus Position
1000 to F000
Far end Near end
Focus Near
Limit
1000: Over Inf
2000: 20 m
3000: 10 m
4000: 6 m
5000: 4.2 m
6000: 3.1 m
7000: 2.5 m
8000: 2.0 m
9000: 1.65 m
A000: 1.4 m
B000: 1.2 m
C000: 0.8 m
D000: 30 cm
(initial setting)
E000: 11 cm
F000: 1 cm
As the distance on the left
will differ due to temperature
characteristics, etc., use as
approximate values.
* The lower 1 byte is fixed at 00.
Wide/Tele Limit Setting
Wide/Tele Limit
Setting Value
Wide Limit Tele Limit
Limit Setting
Value
Zoom
Position
Zoom
Ratio
Zoom
Position
Zoom
Ratio
00 0000 1 4000 30
10 00C4 1.02 3F3B 25.5
20 0188 1.04 3E77 22.7
30 024C 1.06 3DB3 20.7
40 0310 1.08 3CEF 19.1
50 03D4 1.11 3C2B 17.8
60 0498 1.13 3B67 16.7
70 055C 1.15 3AA3 15.7
80 0620 1.18 39DF 14.8
90 06E4 1.2 391B 14
A0 07A8 1.23 3857 13.2
B0 086C 1.26 3793 12.5
C0 0930 1.28 36CF 11.8
D0 09F4 1.31 360B 11.2
E0 0AB8 1.34 3547 10.6
F0 0B7C 1.38 3483 10
FF 0C33 1.41 33CC 9.5
