Locations of Controls
7
3
5
6
4
2
1
Locations of Controls
Main Unit
1 Lens
2 CN901 connector
3 CN903 connector
4 TELE button
Front
Right side
Bottom
Left side
5 WIDE button
6 CN601 connector
7 Tripod screw holes
When a tripod is used, please use 10 mm (
13
/32 in.)
screws to attach it to the camera. Also, please be sure
to attach the tripod securely.
