Sony FD Trinitron KV-29FX64E - C BOARD COMPLETE Parts List

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 63 -
G C
R6108 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6109 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6110 1-216-821-11 RES-CHIP 1K 5% 1/16W
< RELAY >
RY6001 £ 1-755-395-11 RELAY (AC POWER)
RY6002 £ 1-755-389-11 RELAY (AC POWER)
< TRANSFORMER >
T6002 £ 1-437-443-11 TRANSFORMER, CONVERTER (PIT)
T6003 £ 1-424-896-11 TRANSFORMER, LINE FILTER
T6101 £ 1-437-483-11 TRANSFORMER, STANDBY
< THERMISTOR >
TH6002 £ 1-803-540-11 THERMISTOR
* A-1300-354-A C BOARD, COMPLETE
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C7303 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C7305 1-136-207-11 MYLAR 0.047UF 10.00% 400V
C7306 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C7308 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C7309 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C7310 1-163-247-91 CERAMIC CHIP 68PF 5.00% 50V
C7325 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C7326 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C7330 1-136-207-11 MYLAR 0.047UF 10.00% 400V
C7331 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C7333 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C7334 1-163-247-91 CERAMIC CHIP 68PF 5.00% 50V
C7350 1-126-947-11 ELECT 47UF 20.00% 25V
C7351 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C7352 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C7354 1-126-933-11 ELECT 100UF 20.00% 16V
C7355 1-107-967-11 ELECT 1UF 20.00% 400V
C7356 1-136-207-11 MYLAR 0.047UF 10.00% 400V
C7358 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C7359 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C7360 1-163-247-91 CERAMIC CHIP 68PF 5.00% 50V
C7378 1-162-116-00 CERAMIC 680PF 10.00% 2KV
C7379 1-162-114-00 CERAMIC 0.0047UF 2KV
C7380 1-107-662-11 ELECT 22UF 20.00% 250V
C7384 1-162-911-11 CERAMIC CHIP 6PF 0.50PF 50V
C7385 1-162-913-11 CERAMIC CHIP 8PF 0.50PF 50V
C7387 1-162-911-11 CERAMIC CHIP 6PF 0.50PF 50V
C7388 1-162-913-11 CERAMIC CHIP 8PF 0.50PF 50V
C7390 1-162-911-11 CERAMIC CHIP 6PF 0.50PF 50V
C7391 1-162-913-11 CERAMIC CHIP 8PF 0.50PF 50V
< CONNECTOR >
CN7300 * 1-564-508-11 PLUG, CONNECTOR 5P
CN7301 * 1-564-512-11 PLUG, CONNECTOR 9P
CN7311 1-695-915-11 TAB (CONTACT)
CN7333 1-695-915-11 TAB (CONTACT)
< DIODE >
D7300 8-719-911-19 DIODE 1SS119-25TD
D7325 8-719-911-19 DIODE 1SS119-25TD
D7350 8-719-911-19 DIODE 1SS119-25TD
D7375 8-719-991-33 DIODE 1SS133T-77
D7376 8-719-991-33 DIODE 1SS133T-77
D7378 8-719-109-89 DIODE MTZJ-T-77-5.6B
D7379 8-719-109-89 DIODE MTZJ-T-77-5.6B
< IC >
IC7300 8-759-360-83 IC TDA6111Q/N4
IC7325 8-759-360-83 IC TDA6111Q/N4
IC7350 8-759-360-83 IC TDA6111Q/N4
< SOCKET >
J7375 £ 1-251-732-11 SOCKET, CRT
< COIL >
L7375 1-410-671-31 INDUCTOR 47UH
L7376 £ 1-532-637-00 LINK, IC 1A/150V
L7378 1-414-934-21 INDUCTOR 10UH
< TRANSISTOR >
Q7350 8-729-901-06 TRANSISTOR MUN2113T1
Q7352 8-729-421-19 TRANSISTOR MUN2213T1
Q7353 8-729-421-19 TRANSISTOR MUN2213T1
Q7354 8-729-901-06 TRANSISTOR MUN2113T1
Q7355 8-729-421-19 TRANSISTOR MUN2213T1
< RESISTOR >
R7300 1-249-417-11 CARBON 1K 5% 1/4W
R7303 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7304 1-260-095-11 SOLID 470 20% 1/2W
R7305 1-215-903-11 METAL OXIDE 68K 5% 2W
R7309 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7310 1-216-819-11 RES-CHIP 680 5% 1/16W
R7325 1-249-417-11 CARBON 1K 5% 1/4W
R7328 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7329 1-260-095-11 SOLID 470 20% 1/2W
R7330 1-215-903-11 METAL OXIDE 68K 5% 2W
R7334 1-216-819-11 RES-CHIP 680 5% 1/16W
