Sony FD Trinitron KV-29FX64E - D BOARD COMPLETE Parts List

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 64 -
C8114 1-126-964-11 ELECT 10UF 20.00% 50V
C8115 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C8116 1-115-416-11 CERAMIC CHIP 0.001UF 5.00% 25V
C8117 1-115-416-11 CERAMIC CHIP 0.001UF 5.00% 25V
C8118 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C8120 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C8125 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C8126 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C8128 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C8130 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C8131 1-126-964-11 ELECT 10UF 20.00% 50V
C8132 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C8134 1-102-935-00 CERAMIC 2PF 0.25PF 50V
C8135 1-126-964-11 ELECT 10UF 20.00% 50V
C8136 1-126-964-11 ELECT 10UF 20.00% 50V
C8140 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8207 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C8208 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C8209 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C8210 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8801 1-126-947-11 ELECT 47UF 20.00% 25V
C8802 1-126-960-11 ELECT 1UF 20.00% 50V
C8803 1-126-960-11 ELECT 1UF 20.00% 50V
C8804 1-102-114-00 CERAMIC 470PF 10.00% 50V
C8805 1-102-114-00 CERAMIC 470PF 10.00% 50V
C8808 1-102-030-00 CERAMIC 330PF 10.00% 500V
C8809 1-102-030-00 CERAMIC 330PF 10.00% 500V
C8810 1-107-368-11 MYLAR 0.047UF 10.00% 200V
C8811 1-107-368-11 MYLAR 0.047UF 10.00% 200V
C8812 1-162-131-11 CERAMIC 220PF 10.00% 2KV
C8813 1-107-444-11 CERAMIC 100PF 10.00% 2KV
C8814 1-117-640-11 FILM 6800PF 3.00% 1.2KV
C8815 1-117-835-11 FILM 6200PF 3.00% 1.5KV
C8816 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8817 1-125-893-11 FILM 680PF 3.00% 1.5KV
C8818 1-125-893-11 FILM 680PF 3.00% 1.5KV
C8819 1-125-893-11 FILM 680PF 3.00% 1.5KV
C8820 1-125-893-11 FILM 680PF 3.00% 1.5KV
C8824 1-107-846-11 FILM 0.1UF 5.00% 250V
C8825 1-117-663-11 FILM 0.22UF 5.00% 250V
C8826 1-115-518-11 FILM 0.47UF 5.00% 250V
C8827 1-117-660-21 FILM 0.12UF 5.00% 250V
C8828 1-127-681-11 FILM MELF 10000PF 2% 100V
C8829 1-127-680-11 FILM MELF 4700PF 2% 100V
C8830 1-107-655-11 ELECT 47UF 20.00% 250V
C8831 1-102-228-00 CERAMIC 470PF 10.00% 500V
C8832 1-126-941-11 ELECT 470UF 20.00% 25V
C8833 1-126-941-11 ELECT 470UF 20.00% 25V
C8834 1-102-228-00 CERAMIC 470PF 10.00% 500V
C8835 1-102-228-00 CERAMIC 470PF 10.00% 500V
C
D
R7335 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7350 1-249-417-11 CARBON 1K 5% 1/4W
R7356 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7357 1-260-095-11 SOLID 470 20% 1/2W
R7358 1-215-903-11 METAL OXIDE 68K 5% 2W
R7363 1-216-819-11 RES-CHIP 680 5% 1/16W
R7364 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7373 1-216-823-11 RES-CHIP 1.5K 5% 1/16W
R7374 1-216-819-11 RES-CHIP 680 5% 1/16W
R7375 1-249-435-11 CARBON 33K 5% 1/4W
R7376 1-249-429-11 CARBON 10K 5% 1/4W
R7377 1-249-430-11 CARBON 12K 5% 1/4W
R7379 1-216-833-11 RES-CHIP 10K 5% 1/16W
R7380 1-216-833-11 RES-CHIP 10K 5% 1/16W
R7381 1-216-833-11 RES-CHIP 10K 5% 1/16W
R7382 1-202-549-00 SOLID 100 20% 1/2W
R7383 1-216-399-00 METAL OXIDE 6.8 5% 3W
R7385 1-202-549-00 SOLID 100 20% 1/2W
R7387 1-247-735-11 SOLID 47 20% 1/2W
R7389 1-247-881-00 CARBON 120K 5% 1/4W
R7390 1-249-417-11 CARBON 1K 5% 1/4W
R7391 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7392 1-216-819-11 RES-CHIP 680 5% 1/16W
R7393 1-216-823-11 RES-CHIP 1.5K 5% 1/16W
R7394 1-249-417-11 CARBON 1K 5% 1/4W
R7395 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7396 1-216-819-11 RES-CHIP 680 5% 1/16W
R7397 1-216-823-11 RES-CHIP 1.5K 5% 1/16W
R7398 1-249-417-11 CARBON 1K 5% 1/4W
R7399 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
< VARIABLE RESISTOR >
RV7375 1-225-952-11 RES, ADJ, METAL FILM 110M
* A-1640-432-A D BOARD, COMPLETE
4-206-543-01 HEAT SINK
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C8100 1-136-165-00 FILM 0.1UF 5.00% 50V
C8101 1-136-165-00 FILM 0.1UF 5.00% 50V
C8102 1-136-165-00 FILM 0.1UF 5.00% 50V
C8103 1-115-416-11 CERAMIC CHIP 0.001UF 5.00% 25V
C8104 1-115-416-11 CERAMIC CHIP 0.001UF 5.00% 25V
C8105 1-126-947-11 ELECT 47UF 20.00% 25V
C8106 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C8108 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C8109 1-126-947-11 ELECT 47UF 20.00% 25V
C8113 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
