Sony FD Trinitron KV-29FX64E - Page 67

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 67 -
D
R8191 1-215-925-11 METAL OXIDE 22K 5% 3W
R8196 1-249-377-11 CARBON 0.47 5% 1/4W
R8197 1-216-841-11 RES-CHIP 47K 5% 1/16W
R8203 1-208-789-11 METAL CHIP 2K 0.5% 1/10W
R8204 1-216-295-91 SHORT 0
R8205 1-216-295-91 SHORT 0
R8206 1-216-849-11 RES-CHIP 220K 5% 1/16W
R8207 1-216-846-11 RES-CHIP 120K 5% 1/16W
R8209 1-216-295-91 SHORT 0
R8210 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R8211 1-216-833-11 RES-CHIP 10K 5% 1/16W
R8212 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R8215 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R8216 1-208-812-11 METAL CHIP 18K 0.5% 1/10W
R8217 1-216-833-11 RES-CHIP 10K 5% 1/16W
R8219 1-216-841-11 RES-CHIP 47K 5% 1/16W
R8220 1-216-834-11 RES-CHIP 12K 5% 1/16W
R8221 1-216-837-11 RES-CHIP 22K 5% 1/16W
R8223 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
R8224 1-216-827-11 RES-CHIP 3.3K 5% 1/16W
R8456 1-216-845-11 RES-CHIP 100K 5% 1/16W
R8457 1-216-834-11 RES-CHIP 12K 5% 1/16W
R8458 1-216-841-11 RES-CHIP 47K 5% 1/16W
R8459 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R8800 1-247-895-91 CARBON 470K 5% 1/4W
R8804 1-249-408-11 CARBON 180 5% 1/4W
R8805 1-249-408-11 CARBON 180 5% 1/4W
R8806 1-249-411-11 CARBON 330 5% 1/4W
R8807 1-249-411-11 CARBON 330 5% 1/4W
R8808 1-260-340-11 CARBON 10K 5% 1/2W
R8809 1-260-340-11 CARBON 10K 5% 1/2W
R8810 1-215-895-11 METAL OXIDE 3.3K 5% 2W
R8811 1-215-896-00 METAL OXIDE 4.7K 5% 2W
R8812 1-216-461-00 METAL OXIDE 5.6K 5% 2W
R8813 1-215-895-11 METAL OXIDE 3.3K 5% 2W
R8814 1-215-880-00 METAL OXIDE 10 5% 2W
R8815 1-215-880-00 METAL OXIDE 10 5% 2W
R8816 1-216-365-00 METAL OXIDE 0.47 5% 2W
R8817 1-216-361-00 METAL OXIDE 0.22 5% 2W
R8818 1-249-405-11 CARBON 100 5% 1/4W
R8819 1-247-807-31 CARBON 100 5% 1/4W
R8831 1-260-124-11 CARBON 120K 5% 1/2W
R8833 1-202-972-61 FUSIBLE 1 5% 1/4W
R8834 1-260-288-11 CARBON 0.47 5% 1/2W
R8835 1-260-288-11 CARBON 0.47 5% 1/2W
R8836 1-249-432-11 CARBON 18K 5% 1/4W
R8837 1-215-894-11 METAL OXIDE 2.2K 5% 2W
R8838 1-214-905-11 METAL 47K 1% 1/2W
R8839 1-215-894-11 METAL OXIDE 2.2K 5% 2W
R8840 1-247-843-11 CARBON 3.3K 5% 1/4W
H1
R8842 1-260-123-11 CARBON 100K 5% 1/2W
R8843 1-216-833-11 RES-CHIP 10K 5% 1/16W
R8844 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8845 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8851 1-260-123-11 CARBON 100K 5% 1/2W
R8852 1-260-123-11 CARBON 100K 5% 1/2W
R8853 1-260-123-11 CARBON 100K 5% 1/2W
R8854 1-249-425-11 CARBON 4.7K 5% 1/4W
R8856 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R8857 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R8858 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R8859 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R8865 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8866 1-216-295-91 SHORT 0
R8867 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R8869 1-216-837-11 RES-CHIP 22K 5% 1/16W
R8870 1-216-837-11 RES-CHIP 22K 5% 1/16W
R8885 1-208-854-11 METAL CHIP 1M 0.5% 1/10W
R8886 1-208-836-11 METAL CHIP 180K 0.5% 1/10W
R8887 1-216-841-11 RES-CHIP 47K 5% 1/16W
R8888 1-249-441-11 CARBON 100K 5% 1/4W
R8895 1-249-443-11 CARBON 0.47 5% 1/4W
R8896 1-249-443-11 CARBON 0.47 5% 1/4W
R8897 1-215-485-00 METAL 470K 1% 1/4W
R8898 1-215-493-00 METAL 1M 1% 1/4W
R8899 1-215-493-00 METAL 1M 1% 1/4W
< TRANSFORMER >
T8800 £ 8-598-851-50 FBT ASSY NX-4522//Z
T8801 1-437-430-11 TRANSFORMER, FERRITE (HDT)
T8802 1-437-430-11 TRANSFORMER, FERRITE (HDT)
T8852 1-433-487-11 TRANSFORMER, FERRITE (DFT)
* A-1646-243-A MOUNTED PC BOARD, H1
4-206-220-01 HOLDER, LED
< CAPACITOR >
C0992 1-104-665-11 ELECT 100UF 20.00% 25V
C0993 1-102-114-00 CERAMIC 470PF 10.00% 50V
C0994 1-102-129-00 CERAMIC 0.01UF 10.00% 50V
< CONNECTOR >
CN0991 * 1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D0991 8-719-109-89 DIODE MTZJ-T-77-5.6B
D0993 8-719-082-12 DIODE TLHK5190
