Sony FD Trinitron KV-29FX64E - H1 BOARD COMPLETE Parts List; H2 BOARD COMPLETE Parts List

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 68 -
VM
H2H1
* A-1644-119-A MOUNTED PC BOARD, VM
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C7401 1-126-935-11 ELECT 470UF 20.00% 16V
C7403 1-126-935-11 ELECT 470UF 20.00% 6.3V
C7404 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C7405 1-126-933-11 ELECT 100UF 20.00% 16V
C7406 1-126-935-11 ELECT 470UF 20.00% 6.3V
C7407 1-107-364-11 MYLAR 0.01UF 10.00% 200V
C7408 1-107-364-11 MYLAR 0.01UF 10.00% 200V
C7409 1-107-649-11 ELECT 2.2UF 20.00% 250V
C7410 1-130-471-00 MYLAR 0.001UF 5.00% 50V
C7411 1-130-471-00 MYLAR 0.001UF 5.00% 50V
C7412 1-126-935-11 ELECT 470UF 20.00% 16V
C7413 1-126-935-11 ELECT 470UF 20.00% 16V
C7414 1-107-652-11 ELECT 10UF 20.00% 250V
C7415 1-107-363-91 MYLAR 0.0068UF 10.00% 200V
C7418 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C7421 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
< CONNECTOR >
CN7442 * 1-564-508-11 PLUG, CONNECTOR 5P
CN7443 * 1-564-506-11 PLUG, CONNECTOR 3P
CN7444 * 1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
< DIODE >
D7400 8-719-991-33 DIODE 1SS133T-77
D7401 8-719-991-33 DIODE 1SS133T-77
D7403 8-719-991-33 DIODE 1SS133T-77
D7404 8-719-991-33 DIODE 1SS133T-77
D7405 8-719-924-11 DIODE MTZJ-T-77-22
D7406 8-719-924-11 DIODE MTZJ-T-77-22
< COIL >
L7400 1-414-934-21 INDUCTOR 10UH
L7402 1-414-934-21 INDUCTOR 10UH
L7403 1-414-934-21 INDUCTOR 10UH
< TRANSISTOR >
Q7400 8-729-010-29 TRANSISTOR MSD601-RST1
Q7401 8-729-010-29 TRANSISTOR MSD601-RST1
Q7402 8-729-010-29 TRANSISTOR MSD601-RST1
Q7403 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q7404 8-729-216-22 TRANSISTOR 2SA1037K-T-146-R
Q7405 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q7406 8-729-045-05 TRANSISTOR 2SA2005
Q7407 8-729-045-04 TRANSISTOR 2SC5511
< IC >
IC0991 8-742-180-30 HYB IC SBX3081-51(20)
< RESISTOR >
R0992 1-247-807-31 CARBON 100 5% 1/4W
* A-1647-043-A MOUNTED PC BOARD, H2
< CAPACITOR >
C2906 1-126-960-11 ELECT 1UF 20.00% 50V
C2907 1-126-960-11 ELECT 1UF 20.00% 50V
C2913 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C2914 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
< CONNECTOR >
CN2900 1-779-947-11 TERMINAL BLOCK, S
CN2906 * 1-564-524-11 PLUG, CONNECTOR 9P
CN2908 1-564-521-11 PLUG, CONNECTOR 6P
< JACK >
J2900 1-750-264-11 JACK
< COIL >
L0904 1-410-119-11 INDUCTOR 1MH
< RESISTOR >
R0901 1-249-427-11 CARBON 6.8K 5% 1/4W
R0902 1-215-445-00 METAL 10K 1% 1/4W
R0911 1-249-419-11 CARBON 1.5K 5% 1/4W
R0913 1-247-843-11 CARBON 3.3K 5% 1/4W
R0914 1-249-431-11 CARBON 15K 5% 1/4W
R2903 1-249-406-11 CARBON 120 5% 1/4W
R2904 1-249-406-11 CARBON 120 5% 1/4W
R2909 1-247-895-91 CARBON 470K 5% 1/4W
R2910 1-247-895-91 CARBON 470K 5% 1/4W
R2915 1-249-406-11 CARBON 120 5% 1/4W
R2916 1-249-406-11 CARBON 120 5% 1/4W
R2917 1-249-412-11 CARBON 390 5% 1/4W
R2918 1-249-412-11 CARBON 390 5% 1/4W
< SWITCH >
S0900 1-692-979-11 SWITCH, TACTILE
S0901 1-692-979-11 SWITCH, TACTILE
S0902 1-692-979-11 SWITCH, TACTILE
