[2] Read This First
Identifying the parts
Identifying the parts (HDR-AS50)
(on/standby) button
1.
GPS sensor
2.
IR remote receiver (FDR-X3000)
3.
MENU button
4.
Display panel
5.
UP button/DOWN button
6.
REC lamp
7.
REC (Movie/still image) button/ENTER (Menu execute) button
8.
REC/LIVE lamp
9.
(N Mark)
10
.
Lens
11
.
Speaker
12
.
Microphones
13
.
HDMI OUT jack
14
.
Multi/Micro USB terminal
15
.
Mic jack
*1
16
.
CHG (Charge) lamp
17
.
Battery cover
18
.
Battery housing
19
.
Battery ejection lever
20
.
Connector cover (HDMI OUT jack, Multi/Micro USB Terminal/Mic jack)
21
.
REC lamp
22
.
Lock lever
23
.
Screw hole for tripod
*2
24
.
Access lamp
25
.
Memory card insertion slot
26
.
Memory card cover
27
.
When an external microphone (sold separately) is connected, audio cannot be recorded through the built-in microphone.
*1
The length of the corresponding tripod screw should be less than 5.5 mm (7/32 in.).
*2
