Sony FH-211W - Table of Contents; Features

. .
'.
' '
. JABLE OF . CONTENTS . : . . , ii
• "''y ~ ! " ' ' ' ,
Before using
Features .............................................................................................. 3
Precautions
.... . ............. .. .. .. ... ........... .................. .. ............ . .. .............. . 4
To change the AM tuning interval ...... ............................... ..... ...... 4
Location and function
of controls ............................................... 5
Set•up ......... .. ... . .... .. ............ .. ... ....... ....... .. . .. .............. . .. .. : . ...... ............... 8
Connections
...................................... .. .. .. . ..... . ................................. .. . g
System connection...........................................................
....... g
External antenna connection
............ ............... .............. . .. . .. 10
Basic operation
---
Radio broadcast reception ........... .................. ...................... .......... 11
To tune in a station manually- Manual tuning .............. 11
To tune in a preset station-Preset tuning ...... ................ 12
Tape playback .. ................................. .................... ................ ............ . 13
Single deck playback
.. ... ...... .. ..... . .. .... ...... .. .. ..... ...... .............. .. 13
To play back both decks continuously- Relay play
..... 14
Tape recording ........ ...... . ............. ........................... . .. ...... . ...... .......... .. 15
Tape dubbing
............... . ............ .. ...... .. . .. . .. ..... . .............. ...... ...... .. ....... 16
How to use the graph ic equalizer ....................... .. ............ ...... ..... 17
Special applications
Compact disc or record playing ......... .. . ................ .................. .. ... 18
Microphone mixing .......................................................................... 19
To
mix the microphone so und ..... . .. . .. .. .. .. .. . .. .. ..................... 19
To record the mixed sound ...................
...... . .. .. ..................... 19
To keep your system running well
Maintenance ................................................................ . ..................... 20
General
Specifications ........ .. . .... ..... ... ... ........ ............ .... ................... ............... 20
Trouble checks .
.. ... .............................. ..... .. . .. . ... .. .. ............. .. ......... .. .. 22
..
· FEATURES .'' . C.. •
, .._, { '• •• J :¥ I •
, " .... "
Compact hi •density component system
FH-211W consists of an FM stereo FM-AM tuner, a cassette
deck and an integrated amplifier.
Tuner section
• Permits precise tuning of FM/AM s tat ions with the digital
readout on the frequency display.
• A
total of 20 stations of any band can be memorized in any
sequence.
• Station scanning
is possible with MEMORY SCAN.
Amplifier section
• A 7-band graphic equalizer with a spectrum analyzer tor
fine adjustment of tone quality for both recording and
playback.
• DBFB (Dynamic Bass Feedback System)
for obtaining
sufficient bass sounds.
Cassette-deck section
• Relay play for playing both decks consecutively.
•
Two synchro dubb ing speeds available.
3
