HBD-DZ340M/DZ640M/DZ840K/DZ840M/DZ940K
16
2-14. BASE UNIT
2-15. OPTICAL PICK-UP
2 FFC holder
3 two insulator screws
4 two insulator screws
5 two insulator
s
6 two insulators
7 optical pick-up
(KHM-313CAA)
1 two claws
1 two claws
3 two claws
2
chuck cam
4 base unit
